Поз.
Артикул
Описание
7
OIL FILTER
9
HOUSING ,001964
9
HOUSING ,001965
15
FILTER ELEMENT WITH GASKETS
17
SEAL RING FILTER BOWL TO FILTER HEAD
19
SCREW OIL FILTER HOUSING TO OIL FILTER HEAD, UP TO ENGINE 923826 YEAR OF MANUFACTURE 1988
21
SEAL RING FUEL LINE TO FEED PUMP
39
COVER OIL COOLER COVER
39
COVER
39
COVER OIL FILTER, 401-403 129660 404 001964 407 017497
63
THREADED INSERT DE-AERATION LINE TO COOLING WATER LINE
63
THREADED INSERT
63
THREADED UNION OIL FILTER
63
THREADED INSERT
63
THREADED INSERT
71
BUSHING ,421.901-400 005356
73
SEAL RING SPEEDOMETER DRIVE
83
SCREW PLUG , Replaced By: N000908014009
83
SCREW PLUGTO 000 553 03 05,000 553 18 05,
87
SEAL RING INJECTION PUMP
110
VALVE
112
SPRING BY-PASS VALVE
114
SEAL RING
116
SCREW PLUG
134
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
134
SPRING WASHER , Replaced By: N000137008212
142
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
142
HEXALOBULAR BOLT. SCREW SUPPORT TO CYLINDER HEAD
152
HEXAGON HEAD BOLT. SCREW POWER CYLINDER TO BRACKET
152
SCREWTO 001 477 20 01,001 477 21 01
156
SPRING WASHER , Replaced By: N000137008212
156
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
160
SCREW STRAP TO BRACKET
160
SCREW VALVE TO BRACKET M 8X55
160
HEXAGON HEAD BOLT. SCREW CLUTCH PRESSURE PLATE TO FLYWHEEL M 8X1,25X60
160
SCREW , Replaced By: N304017008053
160
SCREW , Replaced By: N304017008043
194
FILTER ELEMENT , Replaced By: A4011800009
194
FILTER ELEMENT RANGE OF DELIVERY
194
FILTER ELEMENT WITH GASKETS
195
SEAL RING FILTER BOWL TO FILTER HEAD
200
FILTER BOWL OIL FILTER BOWL
208
SCREW PLUG BELL HOUSING
226
SEAL RING FROM FUEL TANK TO FUEL TANK
226
SEAL RING FUEL LINE TO FEED PUMP
232
VALVE
234
SPRING BY-PASS VALVE
236
SEAL RING
238
SCREW PLUG
248
SEAL RING FUEL LINE TO FEED PUMP
250
SCREW PLUG , Replaced By: N007604014110
250
SCREW PLUG FUEL TANK
252
SEAL RING FUEL LINE TO FEED PUMP
252
SEAL RING FROM FUEL TANK TO FUEL TANK
254
SEAL RING FROM FUEL TANK TO FUEL TANK
254
SCREW PLUG FUEL TANK
254
SCREW PLUG , Replaced By: A1119970330
254
SCREW PLUG , Replaced By: N007604014110
254
SCREW PLUG, FILLING OIL DRAIN
260
SEAL RING SPEEDOMETER DRIVE
260
SEAL RING
260
SEAL RING OIL DRAIN 30X36 MM
262
SCREW FITTING
264
SEALING RING. SEAL RING ENGINE BREATHING
264
SEAL RING INJECTION PUMP
264
SEAL RING FUEL LINE TO FEED PUMP
264
SCREW PLUG FUEL TANK
264
SCREW PLUG , Replaced By: N007604014110
293
GASKET OIL FILTER TO CYLINDER CRANKCASE
293
GASKET OIL FILTER TO CYLINDER CRANKCASE
306
SEAL RING OIL LINE TO OIL COOLER
306
SEAL RING SPEEDOMETER DRIVE
312
SCREW FITTING
314
SPRING WASHER STEERING COLUMN BRACKET TO CAB
320
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
320
HEXAGON HEAD BOLT P.T.O. TO TRANSMISSION M10X150
320
SCREW SUPPORT WITH EDDY CURRENT BRAKE TO SUPPORT
320
SCREW OIL FILTER TO CYLINDER CRANKCASE
320
SCREW , Replaced By: N304017010047
320
SCREW BRACKET TO SIDE MEMBER M10X35
324
SPRING WASHER
324
SPRING WASHER STEERING COLUMN BRACKET TO CAB
326
SCREW OIL FILTER TO CYLINDER CRANKCASE
422
SCREW PLUGTO 000 553 03 05,000 553 18 05,
422
SCREW PLUG , Replaced By: N000908014009
424
SEAL RING INJECTION PUMP
426
SCREW PLUG
428
SEAL RING SWITCH TO CASE COVER
999
OIL FILTER
999
OIL FILTER RANGE OF DELIVERY,025346
999
FILTER ELEMENT
999
COVER OIL FILTER
999
LEVER THREE-WAY FAUCET,025346
999
VALVE
999
SEAL RING , ELIMINATED,NO LONGER REQUIRED
999
STRAINER , Replaced By: A4011840025
999
STRAINER , Replaced By: A4011840025
999
STRAINER , Replaced By: A4031840025
999
VALVE
999
SCREW FILTER BOWL TO FILTER HEAD
999
HOUSING OIL FILTER BOWL
999
HOUSING , Replaced By: A4011800011
999
OIL COOLER , Replaced By: A0011883001
999
OIL COOLER , Replaced By: A0011881101
999
OIL COOLER , Replaced By: A0011881201
999
OIL COOLER , Replaced By: A0011883101
999
SCREW FLANGE TO PIPE SOCKET
999
SCREW SCREENING PLATE TO CYLINDER HEAD
999
FILTER ELEMENT , Replaced By: A4011840025
999
FILTER ELEMENT , Replaced By: A4011840025
999
FILTER ELEMENT , Replaced By: A4011840025
999
FILTER ELEMENT , Replaced By: A0011843825
999
FILTER ELEMENT
999
FILTER ELEMENT , Replaced By: A4011840025
999
FILTER ELEMENT , Replaced By: A4011840025
999
OIL COOLER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0001886401
999
OIL COOLER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 121799, Replaced By: A0011883101
999
OIL COOLER , Replaced By: A0011883101
999
OIL COOLER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0011883001
999
OIL COOLER , Replaced By: A0011883101
999
OIL COOLER , Replaced By: A0011884001
999
OIL COOLER , ORDER NUMBER 001 188 30 01/29, Replaced By: A0011883701
999
OIL COOLER
999
OIL COOLER , ORDER NUMBER 001 188 37 01/29, Replaced By: A0011888901
999
OIL COOLER , ORDER NUMBER 001 188 40 01/29, Replaced By: A0021882301
999
OIL COOLER ,907 845891
999
SEAL RING , Replaced By: A0009976049
999
VALVE , NOT USED
999
FILTER ELEMENT , Replaced By: A0001801809
999
FILTER ELEMENT
999
OIL FILTER , Replaced By: A4031801110
999
OIL FILTER , Replaced By: A4011800210
999
OIL COOLER
999
SCREW , Replaced By: N910105016029
999
SPRING
999
SPRING
999
SCREW INTERMEDIATE PIECE TO CYLINDER CRANKCASE
999
FITTING , Replaced By: A0029977472
999
SCREW PLUG , Replaced By: A4039970230
999
SCREW PLUG , Replaced By: A4429970030
999
FLANGE HEATING CONNECTION LOCK,5 301949
999
OIL FILTER , Replaced By: A0011840408
999
FILTER ELEMENT , Replaced By: A4011800009
999
GASKET
999
FILTER BOWL OIL FILTER BOWL
999
COVER , Replaced By: A4031801438
999
OIL FILTER , Replaced By: A0011840408
999
COVER , Replaced By: A0011840408
999
COVER OIL FILTER,OIL COOLER
999
FILTER ELEMENT , Replaced By: A4021800009
999
VALVE , Replaced By: A4031840132
999
GASKET , Replaced By: A4031840380
999
GASKET , Replaced By: A4421880280
999
GASKET , Replaced By: N917003026000
999
SCREW PLUG
999
FITTING FROM INTAKE MANIFOLD TO VACUUM LINE, FROM IDENT NO.002799-360785
999
PARTITION PANEL ,001964
999
HOUSING , Replaced By: A4041800637
999
COVER OIL FILTER
999
COVER OIL COOLER HOUSING
999
GASKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 401-403, 421-423, 441-443 735001 404, 424, 444 051301 407, 447015077, Replaced By: A4441840080
999
GASKET , Replaced By: A4441880080
999
BAFFLE PLATE OIL COOLER HOUSING,001965
999
LINE
999
COVER , Replaced By: A4071800438
999
COVER
999
COVER , Replaced By: A4441801538
999
CLAMPING BRACKET OIL FILTER TO BRACKET,5 218089
999
BRACKET OIL LINES
999
BRACKET OIL LINES
999
COVER
999
HOUSING , Replaced By: A4241800037
999
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4421312080
999
GASKET TO PLUG AIR COMPRESSOR CONNECTION ON CYLINDER CRANKCASE
999
GASKET , Replaced By: A4421880580
999
SCREW PLUG SHIFTING SHAFT DETENT
999
BRACKET OIL FEED LINE TO OIL FILTER
999
OIL FILTER COVER
999
SPACER
999
FITTING OIL FEED LINE TO CYLINDER CRANKCASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
OIL LINE OIL FEED LINE TO CYLINDER CRANKCASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
OIL LINE OIL FEED LINE TO CYLINDER CRANKCASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
OIL LINE OIL LINE TO CYLINDER CRANKCASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
SCREW PLUG OIL LINES ON LONG-LIFE OIL FILTER
999
BRACKET OIL FEED LINE TO OIL FILTER
999
SCREW PLUG , Replaced By: A1119970330
999
WASHER EXHAUST MUFFLER TO STRAP
999
SPRING WASHER , Replaced By: N000137008212
999
WASHER VIBRATION ABSORBER TO BRACKET
999
LOCK RING SHIFT LEVER BEARING
999
SCREW PLUG TO PLUG THE OIL PASSAGES
999
SCREW PLUG FRONT COVER
999
SCREW PLUG OIL FILLING
999
SCREW INTERMEDIATE PIECE TO CYLINDER CRANKCASE
999
CAP BOLT. SCREW BUMPER TO BRACKET,5 398606
999
SCREW , Replaced By: N304017008018
999
SCREW , Replaced By: N304014010004
999
SCREW , Replaced By: N304017008018
999
SCREW , Replaced By: N304017010047
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
