Поз.
Артикул
Описание
9
GEAR DRIVE GEAR ON CAMSHAFT
17
DISC SPRING
25
LOCK
33
SCREW , Replaced By: N304017010047
41
COMPRESSOR ONE-CYLINDER,WATER-COOLED, ATTACHED VERTICALLY ON THE LEFT,002638
41
COMPRESSOR ONE-CYLINDER,WATER-COOLED, ATTACHED VERTICALLY ON THE LEFT,002639
41
COMPRESSOR
41
COMPRESSOR ONE-CYLINDER,WATER-COOLED, ATTACHED VERTICALLY ON THE LEFT
49
HOUSING , Replaced By: A4071300610
49
HOUSING , Replaced By: A4471310215, +001A4471310121, +001A4471310280, +002N000931008210
57
THREADED INSERT
65
THREADED INSERT ,5 462573
73
LOCK BEARING FLANGE IN TIMING CASE & AIR COMPRESSOR HOUSING,RESP.
81
SPACER TUBE
89
DRIVE GEAR ON AIR COMPRESSOR CRANKSHAFT
89
DRIVE GEAR ON AIR COMPRESSOR CRANKSHAFT
94
SEAL RING FROM FUEL TANK TO FUEL TANK
97
CRANKSHAFT
97
CRANKSHAFT , Replaced By: A4031300214
97
CRANKSHAFT , 401-403,421-423,440-443,445,446888000 407,427,447062251, Replaced By: A4031311216, +001A4071300445, +001A0001321410
97
CRANKSHAFT , Replaced By: A4031310716
105
SCREW DRIVE GEAR TO CRANKSHAFT
113
CYLINDR. ROLLER BEARING AIR COMPRESSOR BEARING
113
CYLINDR. ROLLER BEARING , Replaced By: A0079813001
121
FLANGE , Replaced By: A4071300445
121
FLANGE AIR COMPRESSOR BEARING FLANGE
129
BUSHING
129
BUSHING , Replaced By: A0001314250
137
SEAL RING , Replaced By: A0149976148
137
SEAL RINGTO 388 476 71 69
145
CONNECTING ROD
153
CLAMPING SLEEVE
161
SCREW THERMOSTAT HOUSING TO WATER PUMP M 8X38
169
BEARING SHELL UPPER AND LOWER HALVES
177
CYLINDER LINER WITH PISTON
177
CYLINDER LINER WITH PISTON,AIR-COOLED
177
CYLINDER LINER , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 264430, Replaced By: A4021300608
185
PISTON RING , Replaced By: A0001318611
185
PISTON RING GROOVES I AND II
193
PISTON RING GROOVE III
193
PISTON RING , Replaced By: A0001318611
201
PISTON RING GROOVE IV
209
PISTON PINTO 403 130 05 17
209
PISTON PIN ,264430
217
SNAP RING
241
EXPANSION PLUG , Replaced By: A4039970620
241
EXPANSION PLUG P.T.O. HOUSING
249
GASKET OIL FILTER TO CYLINDER CRANKCASE
249
GASKET OIL FILTER TO CYLINDER CRANKCASE
249
GASKET TO PLUG AIR COMPRESSOR CONNECTION ON CYLINDER CRANKCASE
249
GASKET , Replaced By: A4421312080
249
GASKET , Replaced By: A4421310080
257
SCREW , Replaced By: N304017008033
257
SCREW BRACKET TO SIDE MEMBER
265
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
273
SPRING WASHER , Replaced By: N000137008212
281
CYLINDER HEAD
281
CYLINDER HEAD LESS DISC VALVE
281
CYLINDER HEAD WITH DISC VALVE, 407 030936 427 002637 447.901/200 030936 447.905/906/908/910/911/912/951 001443
281
CYLINDER HEAD , Replaced By: A4071300519
285
THREADED INSERT REPAIR SIZE, TO BE ADAPTED DURING ASSEMBLY
289
SPACER RING PRESSURE DISC TO INTERMEDIATE PLATE
289
SPACER RING PRESSURE DISC TO INTERMEDIATE PLATE TO 000 130 24 19/25 19/26 19
297
SCREW PRESSURE DISC TO INTERMEDIATE PLATE M 6X20
305
SCREWTO 376 131 74 01
313
GASKET , Replaced By: A4421310780
313
GASKET
313
GASKET INTERMEDIATE PLATE TO CYLINDER HEAD
313
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4421312980
313
GASKET , Replaced By: A4421312180
313
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4421311980
313
GASKET , Replaced By: A4421311980
313
GASKET , Replaced By: A0011317380
321
GASKET , Replaced By: A4421310680
321
GASKET , Replaced By: A4421310980
321
GASKETWABCO
321
GASKET CYLINDER HEAD TO CYLINDER LINER
321
GASKET
329
SCREW STRAP TO BRACKET
337
SPRING WASHER , Replaced By: N000137008212
345
SCREW PLUG , Replaced By: N000908022011
353
SCREW PLUG , Replaced By: N000908026008
357
SCREW PLUG , Replaced By: N000908014009
361
ADAPTER FITTINGTO 376 131 74 01
369
SEAL RING LINE CONNECTION
377
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
381
SEAL RING INJECTION PUMP
385
CAP , Replaced By: A4421310021
393
GASKET OIL FILTER TO CYLINDER CRANKCASE
393
GASKET OIL FILTER TO CYLINDER CRANKCASE
393
GASKET TO PLUG AIR COMPRESSOR CONNECTION ON CYLINDER CRANKCASE
393
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4421312080
393
GASKET
417
CAP COVER TO AIR COMPRESSOR HOUSING,048083048474
425
SEAL RING COVER TO AIR COMPRESSOR HOUSING
433
SCREW INTAKE PIPE-SOCKET TO BRACKET
441
SPRING WASHER , Replaced By: N000137008212
449
REPAIR KIT , Replaced By: A4021300220
457
VALVE AIR COMPRESSOR CYLINDER HEAD TO 000 130 24 19/25 19/26 19
457
PARTS KIT AIR COMPRESSOR CYLINDER HEAD
457
REPAIR KIT , Replaced By: A4421300720
457
REPAIR KIT , Replaced By: A4421300720
457
REPAIR KIT , Replaced By: A0001307620
457
REPAIR KIT , Replaced By: A4021300320
461
GASKET KIT , Replaced By: A4071311080
461
GASKET KIT , Replaced By: A4751300215
461
COMPRESSOR AIR COMPRESSOR
461
GASKET KIT AIR COMPRESSOR,002638
465
GASKET
469
REPAIR KIT CRANKSHAFT
473
SCREW INJECTION PUMP DRIVE TO TIMING CASE M 8X140
481
SCREW CLUTCH TO FLYWHEEL,760271
489
SCREWM 8X28
489
SCREW , Replaced By: N304017008024
497
SPRING WASHER , Replaced By: N000137008212
507
SUPPORT COOLING WATER LINES
508
CLAMP , Replaced By: N916016010211
509
HEX. HEAD SCREW. SCREW BRACKET TO INJECTION PUMP
510
NUT BALL PIVOT TO LEVER
519
INTAKE PIPE AIR COMPRESSOR
528
CLAMP HOSE TO BRACKET 25/20,5 206397
536
SCREW , Replaced By: N304017008016
544
SPRING WASHER , Replaced By: N000137008212
552
NUT , Replaced By: N304032008006
561
BRACKET AIR-COMPRESSOR AIR INTAKE
569
PIPE BEND AT AIR COMPRESSOR
576
SEAL RING FROM PIPE ELBOW TO AIR COMPRESSOR
585
NUT , Replaced By: N080705026003
593
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
593
CLAMP25-40X13 MM
999
SEALING COMPOUND TIMING CASE COVER TO TIMING CASE, UP TO ENGINE 978,979 331710 YEAR OF MANUFACTURE 1994
999
SEALING COMPOUND. SEALANT100 G.
