Поз.
Артикул
Описание
215
SHIM
220
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
220
SCREW ENGINE SUPPORT TO CYLINDER CRANKCASE M 12X1.5X55
220
SCREW SUPPORTING ARM TO ENGINE
220
SCREW CONSOLE TO FRAME SIDE MEMBER
224
SPRING WASHER CAB FLOOR
224
SPRING WASHER STEERING COLUMN BRACKET TO CAB
522
PUMP (MANUAL AUXILIARY PUMP)
522
PUMP (MANUAL AUXILIARY PUMP)
544
HOLLOW SCREW FOR HORIZONTAL MOUNTING OF HAND PUMP TO FEED PUMP
545
FITTING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0069971672
545
FITTING
546
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
546
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
547
FITTING WATER SEPARATOR
548
FITTING FUEL FILTER
548
FITTING HAND PUMP TO FUEL FILTER
549
SEAL RING INJECTION PUMP
550
BRACKET
550
SUPPORT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4420921040
552
SCREW ENGINE SUPPORT TO CYLINDER CRANKCASE M 12X1.5X55
553
SCREW BRACKET AND CLAMP M6X20
553
SCREW , Replaced By: N304017006020
554
SPRING WASHER LICENSE PLATE TO BRACKET
584
HEXAGON HEAD BOLT BRACKET TO BRACKET
584
SCREW , Replaced By: N304017010002
585
SPRING WASHER STEERING COLUMN BRACKET TO CAB
588
BRANCH-OFF FITTING BRACKET TO TIMING CASE COVER
590
PIPE ELBOW TO ENGINE
591
HOLLOW SCREW FITTING LINE CONNECTION
594
FITTING FUEL LINE TO HAND PUMP
596
SEAL RING INJECTION PUMP
596
SEAL RINGTO 000 553 03 05,000 553 18 05,
598
CONNECTOR FUEL FEED AND FUEL RETURN TO FUEL DISTRIBUTOR
600
SCREW STRAP TO EXHAUST MUFFLER
600
SCREW VALVE TO BRACKET M 8X55
600
SCREW , Replaced By: N304017008043
602
NUT , Replaced By: N304032008006
602
NUT
622
LINE FROM DISTRIBUTOR TO PREFILTER
624
LINE FROM PREFILTER TO HAND PUMP
624
LINE FROM PREFILTER TO HAND PUMP
624
LINE FROM PREFILTER TO HAND PUMP
626
LINE FROM MANUAL PUMP TO FEED PUMP
626
LINE FROM MANUAL PUMP TO FEED PUMP
626
LINE FROM MANUAL PUMP TO FEED PUMP
626
LINE FROM MANUAL PUMP TO FEED PUMP
628
LINE FROM FEED PUMP TO FILTER
628
LINE FROM FUEL DISTRIBUTOR TO FUEL LINE CONNECTOR
628
LINE FROM FEED PUMP TO FILTER
628
LINE FROM FEED PUMP TO FILTER
702
LINE FROM FUEL FILTER TO INJECTION PUMP
702
LINE FROM FUEL FILTER TO INJECTION PUMP
702
LINE FROM FUEL FILTER TO INJECTION PUMP
702
LINE FROM FUEL FILTER TO INJECTION PUMP
704
LINE FROM FUEL FILTER TO DISTRIBUTOR
706
LINE FROM INJECTION PUMP OVERFLOW VALVE TO RETURN CONNECTION
706
LINE FROM INJECTION PUMP OVERFLOW VALVE TO RETURN CONNECTION
706
LINE FROM INJECTION PUMP OVERFLOW VALVE TO RETURN CONNECTION
706
LINE FROM INJECTION PUMP OVERFLOW VALVE TO RETURN CONNECTION
708
FITTING WATER SEPARATOR
724
HOLLOW SCREW FUEL LINE TO FEED PUMP
724
HOLLOW SCREW FUEL LINE TO FEED PUMP
724
HOLLOW SCREW FOR HORIZONTAL MOUNTING OF HAND PUMP TO FEED PUMP
724
HOLLOW SCREW
724
HOLLOW SCREW AT FEED PUMP,VB112577
724
HOLLOW SCREW 3/2-WAY VALVE,CONNECTION: "2,3"
726
FITTING WATER SEPARATOR
752
SEAL RING , Replaced By: N007603010110
752
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
752
SEAL RING PNEUMATIC VALVE
752
SEAL RINGTO 000 553 03 05,000 553 18 05,
752
SEAL RING INJECTION PUMP
830
HOSE LEAK LINE, ORDER BY THE METER
830
HOSE PLASTIC PIPE,K 223529
830
HOSE , Replaced By: A0119977782
830
HOSE , Replaced By: A0119977782
830
HOSE , Replaced By: A0119977782
830
HOSE , Replaced By: A0119977782
856
BASE , Replaced By: A3142030084
868
CLAMP LINE MOUNTING
868
CLAMP HEATER-PLUG/SOLENOID-VALVE BRANCH-OFFS TO NOZZLE HOLDER,K 092646
868
CLAMP CABLE HARNESS MOUNTING
868
CLAMP AT BRACKET
868
CLAMP , Replaced By: N916016010211
868
CLAMP , Replaced By: N000000001045
868
CLAMP BATTERY CABLE TO CROSS MEMBER
874
CLAMP
876
SPACER TUBE FRONT POSITION LAMP
882
SCREW FUEL LINE TO BRACKET M 6X12
882
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
882
SCREW BATTERY CABLE TO BRACKET M6X45
882
SCREW FUEL LINE TO INTAKE MANIFOLD
882
SCREW LICENSE PLATE TO BRACKET
882
SCREW , Replaced By: N304017006020
884
HEXAGON HEAD BOLT. SCREW OIL SEPARATOR TO TRANSMISSION CASE
884
SCREW CLAMP TO EXHAUST PIPE AND TO FLEXIBLE METAL TUBE M 8X25
884
SCREW BRACKET TO SIDE MEMBER
887
NUT SPRING-LOADED PUSH ROD
887
NUT
887
HEXAGON NUT. NUT , Replaced By: N913023008002
999
CLAMPING BRACKET FILTER HOUSING TO PUMP
999
SEPARATOR (WATER SEPARATOR)
999
NUT
999
BANJO UNION FUEL LINES AND BREATHING
999
STUD
999
CLAMPING PIECE FUEL FILTER TO BRACKET,012710
999
FITTING RETURN
999
LOOM TIE LINE MOUNTING
999
HOLLOW SCREW FUEL LINES TO SOLENOID VALVE
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
999
INTERMEDIATE PIECE AT INJECTION PUMP
999
LINE FROM FUEL DISTRIBUTOR TO FEED PUMP
999
LINE FROM INJECTION PUMP OVERFLOW VALVE TO T-FITTING
999
LINE FROM FUEL FILTER TO INJECTION PUMP
999
LINE FROM FUEL FEED PUMP TO DISTRIBUTOR,062710
999
BRACKET , Replaced By: A4220901241
999
FILTER , Replaced By: A4420900452
999
PLATE LINE MOUNTING,920657
999
LINE
999
HOLLOW SCREW FUEL LINE LEADING TO FUEL PUMP
999
LINE FROM INJECTION PUMP OVERFLOW VALVE TO RETURN CONNECTION, NOT USED
999
LINE FROM FEED PUMP TO FILTER, NOT USED
999
LINE , Replaced By: A4470700432
999
LINE FROM FUEL FILTER TO INJECTION PUMP, NOT USED
999
LINE , Replaced By: A4470700332
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
LOCK WASHER BRACKET TO SUPPORTING ARM
999
NUT , Replaced By: N304032008006
999
WASHER , Replaced By: N007349008007
999
WASHER
999
SEAL RING SCREW PLUG
999
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
SCREW SUPPORT TO FENDER
999
HEXAGON HEAD BOLT. SCREW BRACKET TO CROSS MEMBER
999
COMBINATION BOLT LEFT & RIGHT CHARGE AIR PIPES TO CYLINDER HEAD M 8X93
999
NUT. UNION NUT RETURN
