Поз.
Артикул
Описание
5
PULLEY TWO-GROOVE
8
SUPPORT ALTERNATOR
11
BUSHING
14
SCREW END PIECE TO EXHAUST PIPE M 12X30
14
SCREW , Replaced By: N304017012020
20
HEXAGON HEAD BOLT BEARING BRACKET TO SIDE MEMBER M 12X50
20
SCREW , Replaced By: N308676012011
20
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
20
HEXAGON HEAD BOLT. SCREW THROTTLE HOUSING TO FRONT EXHAUST PIPE M 12X70
26
NUT BRACKET TO SIDE MEMBER M12X1.5
29
CLAMPING BOLT (CLAMPING BOLT)
32
BUSHING
35
CLAMPING PIECE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3141550228
35
CLAMPING PIECE TIGHTENER PULLEY
38
NUT TIGHTENER PULLEY TO LEVER
41
SCREW STEERING SUPPORT TO FRAME M 10X75
41
SCREW BRACKET TO FRAME
41
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
53
WASHER RADIATOR TO RUBBER MOUNTING
56
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
57
NUT BRACKET TO SIDE MEMBER
57
NUT. HEXAGON NUT STRAP TO CONSOLE M12X1.5
59
COVER
62
GASKET
65
NUT BALL PIVOT TO LEVER
68
SPRING WASHER LICENSE PLATE TO BRACKET
