Поз.
Артикул
Описание
1
NUT . M6 WAF 10
2
HORIZONTAL STRUT FRONT PA , H 99999820030103 J 00000020030103
2
HORIZONTAL STRUT FRONT PA
2
STIFFENING
2
HORIZONTAL STRUT FRONT PA , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. H 16336620000619, Replaced By: Q0001243V013000000
2
HORIZONTAL STRUT FRONT PA , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. H 35968220010625, Replaced By: Q0001243V014000000
2
HORIZONTAL STRUT FRONT PA R.H.D., 20020408
2
STIFFENING R.H.D.
2
HORIZONTAL STRUT FRONT PA R.H.D., H 50002020020211
3
BOLT STIFFENING TO CROSS MEMBER, K 00005320060929
3
FLAT HEAD SCREW WITH ROUN
3
FEMALE TORX SCREW M6 X 20
3
FEMALE TORX SCREW M6 X 20 , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. H 16336620000619, Replaced By: Q0008270V000000000
4
SCREW DG 60 X 22Z MICRO-E
5
HOLDER INSTRUMENT PANEL F CO-DRIVER'S SIDE
5
HOLDER INSTRUMENT PANEL F CO-DRIVER'S SIDE
6
MOUNTING KEY CROSSMEMBER
7
SCREW DG80 X 62 MICRO-ENC
7
SCREW DG 80 X 56 MICRO-EN
8
RUBBER WASHER 28X6.5
9
BOLTM8 X 20 - 8.8
10
STAY CROSS MEMBER TO TUNNEL
10
VERTICAL STRUT , Replaced By: Q0001118V014000000
10
VERTICAL STRUT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. H 30002020010108, Replaced By: Q0001118V011000000
10
VERTICAL STRUT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. H 37881420010903, Replaced By: Q0001118V012000000
10
VERTICAL STRUT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. H 50002020020211, Replaced By: Q0001118V013000000
11
BOLTPT DG40 X 16 Z
12
CROSSMEMBER COCKPIT MAGNE CROSS MEMBER BELOW INSTRUMENT PANEL, Replaced By: Q0007740V015000000
12
CROSSMEMBER COCKPIT MAGNE CROSS MEMBER BELOW INSTRUMENT PANEL, H 50002020020211
12
CROSSMEMBER COCKPIT MAGNE CROSS MEMBER BELOW INSTRUMENT PANEL, H 30002020010108, Replaced By: Q0001112V010000000
12
CROSSMEMBER COCKPIT MAGNE CROSS MEMBER BELOW INSTRUMENT PANEL, H 30002020010108, Replaced By: Q0001112V011000000
12
CROSSMEMBER COCKPIT MAGNE CROSS MEMBER BELOW INSTRUMENT PANEL, Replaced By: Q0007740V013000000
12
CROSSMEMBER COCKPIT MAGNE CROSS MEMBER BELOW INSTRUMENT PANEL, Replaced By: Q0007740V014000000
12
CROSSMEMBER COCKPIT MAGNE CROSS MEMBER BELOW INSTRUMENT PANEL, H 50002120020211
13
SCREW DG 80 X 56 MICRO-EN DRIVER'S SIDE DG 80 X 28.5
14
HOLDER INSTRUMENT PANEL F DRIVER'S SIDE
14
HOLDER INSTRUMENT PANEL F DRIVER'S SIDE, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. H 32397420010319, Replaced By: Q0001557V009000000
14
HOLDER INSTRUMENT PANEL F DRIVER'S SIDE, Replaced By: Q0001557V010000000
19
HORIZONTAL STRUT FRONT PA , 20020408
20
ADAPTER PLATE COCKPIT CRO
21
EXPANSION RIVET ORNAMENTAL COVER TO BUMPER
