Поз.
Артикул
Описание
12
FUEL TANK , CONVERSION TO PLASTIC FUEL TANK POSSIBLE WITH MANUFACTURER'S CONFIRMATION
12
FUEL TANK SHEET METAL VERSION, 059607(WHC: WDB) 904078(WHC: VAG)
12
FUEL TANK , Replaced By: A4604701201
14
SEAL RING
15
FILLER NECK
16
FUEL STRAINER
16
SCREW PLUG , Replaced By: A1114700686
16
SCREW PLUG , Replaced By: A1114700586
19
FILLER NECK
19
FILLER NECK
20
FUNNEL , Replaced By: A1694700029
25
EXTENSION BETWEEN FUEL TANK AND FILLER NECK 215 MM, 059607(WHC: WDB) 904078(WHC: VAG)
28
FUEL STRAINER
28
FUEL STRAINER
28
FUEL STRAINER
28
FUEL STRAINER
30
EXTENSION FUEL STRAINER SCREEN
38
FILLER CAP
38
FILLER CAP , 055661 903740
38
FILLER CAP , Replaced By: A4604700230
38
FILLER CAP , Replaced By: A4604700230
39
SEAL RING
40
CHAIN
43
SEAL RING FUEL STRAINER SCREEN SEALING
45
SCREW
54
LOCK WASHER STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET
60
PROTECTOR , Replaced By: A4604750346
60
PROTECTIVE PLATE FUEL TANK
62
CLIP
63
BRACKET FILLER CAP
66
CHAIN , Replaced By: N005685002105
66
CHAIN TO MOUNT TOW-ROD 2,0
68
GUIDE SIGN , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 658987 F 932311, Replaced By: A1245849517
68
GUIDE SIGN , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 658987 F 932311, Replaced By: A1245849617
68
GUIDE SIGN REFUELLING PLATE, IN GERMAN
68
GUIDE SIGN REFUELLING PLATE, IN GERMAN
68
GUIDE SIGN REFUELLING PLATE, IN GERMAN, ONLY APPLICABLE TO VEHICLES EQUIPPED WITH CATALYTIC CONVERTER
132
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
134
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
136
NUT BRACKET TO SUPPORT AND TO END PIECE
999
VALVE
999
INSULATION
999
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
999
LINE12 MM, ORDER BY THE METER4 691315
999
VALVE COMBINATION VALVE,906515
999
FUEL FILTER
999
FUEL FILTER
999
FUEL FILTER
999
FUEL PUMP , Replaced By: A0030915301
999
FUEL PUMP , ONLY FOR R.S.A.
999
LOOM TIE FLEXIBLE SHAFT
999
HOSE CLAMP LINE MOUNTING
999
CLAMP BOOT TO STEERING,V 207570
999
LOOM TIE LINE MOUNTING
999
HOSE FROM RETURN LINE TO FUEL TANK, 059608(WHC: WDB) 904079(WHC: VAG)
999
HOSE FUEL PUMP
999
FUEL STRAINER
999
GROMMET
999
LOOM TIE , Replaced By: A1149970590
999
FUEL HOSE FROM FUEL FILTER TO FUEL ACCUMULATOR, 107.024 025530 107.044 053366 116.032,033 089514
999
HOSE TO ELEMENT AT FRONT SEAT
999
GROMMET FOR PASSAGE OF LINE
999
BOOT , 059608(WHC: WDB) 904079(WHC: VAG)
999
BRACKET FUEL PUMP AND FUEL FILTER
999
DAMPING STRIP40.5X18X18 MM
999
FUEL TANK , Replaced By: A4604700701
999
FUEL FILLER CAP. FILLER CAP LESS BREATHING, LESS KEYS, LOCK DEFINED, STATE LOCK NUMBER WHEN ORDERING
999
STRAP
999
BRACKET FUEL FILTER TO FUEL ACCUMULATOR
999
FUEL TANK , Replaced By: A4604701201
999
BRACKET AT VALVE
999
SEAL RING
999
SCREW PLUG , Replaced By: A1104700486
999
BRACKET
999
BRACKET
999
EXTENSION CONNECTION OF FUEL TANKS
999
EXTENSION , Replaced By: A4604730509
999
PROTECTIVE PLATE AT TANK, 059607(WHC: WDB) 904078(WHC: VAG)
999
SHIM345X35 MM
999
SHIM LEFT TO A 461 470 00 04
999
SHIM RIGHT FUEL TANK, 059608(WHC: WDB) 904079(WHC: VAG)
999
DAMPING STRIP AT FRAME ABOVE FUEL TAK
999
HOSE FUEL LINE LEADING TO FILTER 50 MM
999
HOSE FROM FILTER TO INJECTION PUMP 185 MM
999
LINE , Replaced By: A0004290801
999
HOSE DE-AERATION,055662
999
HOSE FROM FILTER TO THERMOSTAT 140 MM
999
HOSE BETWEEN BREATHER PIPE AND FILLER NECK, 059608(WHC: WDB) 904079(WHC: VAG)
999
HOSE FROM FUEL FILTER II TO FUEL ACCUMULATOR
999
HOSE FROM FUEL FILTER I TO FUEL PUMP II
999
HOSE BETWEEN BREATHER AND GRAVITIY VALVE
999
LINE , Replaced By: A0004290801
999
LINE FROM FUEL PUMP II TO FUEL FILTER II
999
LINE , Replaced By: A0004290801
999
RING FILLER CAP
999
BUFFER BRACKET TO FRAME
999
FUEL TANK PARTS KIT, CONVERSION TO PLASTIC FUEL TANK POSSIBLE WITH MANUFACTURER'S CONFIRMATION ORDER ADDITIONALLY: A 463 476 24 26
999
BRACKET FILLER NECK TO BODY, NOT USED
999
COVERING HEAT INSULATION FUEL TANK TO A 461 470 00 04
999
FILLER NECK
999
FILLER CAP
999
FILLER CAP
999
FILLER NECK
999
FILLER CAP
999
FILLER NECK
999
FILLER NECK
999
BREATHER PIPE , Replaced By: A0004291001
999
BREATHER AT FRAME ABOVE FUEL TAK
999
HOSE BETWEEN BREATHER PIPE AND FUEL TANK
999
BRACKET PUMP,FILTER & FUEL ACCUMULATOR TO BRACKET
999
CLAMP , Replaced By: A0005465143
999
HOSE FUEL HOSE TO FUEL PUMP 120 MM, ORDER BY THE METER
999
CYLINDRICAL PIN DIFFERENTIAL LOCK
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
SCREW , Replaced By: N304017005011
999
SEAL RING FITTING TO AXLE HOUSING
999
SEAL RING LINE CONNECTION
999
SCREW COVER PLATE TO BRACKET
999
RIVET BRACKET TO CAB, 055661 903740
999
NUT BRACKET TO BATTERY/APPARATUS SUPPORT,5 579088
999
NUT SENDER UNIT
999
NUT PUMP TO BRACKET
999
NUT , Replaced By: N913004006001
999
SCREW FILLER NECK M 6X16
999
NUT EXHAUST BRAKE VALVE, CONNECTION: "20"
999
HOLLOW SCREW HEATING CONNECTION
999
CLAMP LINE MOUNTING
999
CLAMP LINE CONNECTION
999
CLAMP
999
CLAMP , Replaced By: A0059970190
999
CLAMP , Replaced By: A0069972790
999
CLAMP , Replaced By: A0069970890
999
HOSE LEAK LINE, ORDER BY THE METER
999
HOSE ADDITIONAL FUEL TANK, ORDER BY THE METER
999
HOSE FUEL LINE TO TANK 13.5 X 7.5 MM, ORDER BY THE METER
999
CLAMP CHECK VALVE,K 169122
