Поз.
Артикул
Описание
3
HOSE DELIVERY LINE
5
THREADED CONNECTION. SCREW CONNECTION OIL DISTRIBUTION
6
NUT. UNION NUT LINE CONNECTION
8
CUTTING RING. GLAND LINE CONNECTION
11
SCREW CONNECTION COMPRESSED AIR LINE TO WHEEL HUB, Replaced By: N000000006458
11
THREADED CONNECTION COMPRESSED AIR LINE TO WHEEL HUB
13
UNION NUT LINE CONNECTION
13
UNION NUT LINE CONNECTION, Replaced By: N000000006239
15
GLAND , Replaced By: A0019901967
15
SEAL CONE LINE CONNECTION
24
PIPE RETURN LINE
29
HOSE FROM STEERING GEAR ON COOLING LINE
30
HOSE CLAMP LINE MOUNTING
35
LINE COOLING LINE
36
GROMMET BRAKE CABLE PASSAGE IN CONSOLE
37
HOSE FROM STEERING GEAR ON COOLING LINE
38
HOSE CLAMP LINE MOUNTING
39
HOSE CLAMP LINE MOUNTING
40
LINE FROM COOLING LINE TO POWER STEERING PUMP
48
SCREW PUMP TO BRACKET M 6X20
50
NUT SPRING-LOADED PUSH ROD
53
NUT PUMP TO BRACKET
56
WASHER
59
WASHER COMPRESSED AIR LINE TO BRACKET
62
SCREW STEERING TO FRAME
62
HEXAGON HEAD BOLT STEERING TO FRAME M12X1.5X240
65
WASHER
68
NUT STRUT TO PROPELLER SHAFT BEARING BRACKET
71
PLATE STEERING TO FRAME
