Поз.
Артикул
Описание
190
STEERING BRACKET RIGHT, 10/20 695199 50/60 695577 8 0000014 2827078 000001-8 001702
190
STEERING BRACKET AT FRAME, 10/20 695198 50/60 695576
193
STEERING BRACKET LEFT, 10/20 695199 50/60 695577 8 0000014 2827078 000001-8 001702
196
STEERING SUPPORT RIGHT,4 282708
196
STEERING SUPPORT RIGHT,4 282708
196
STEERING SUPPORT
196
STEERING SUPPORT
199
STEERING SUPPORT REAR,4 282708
199
STEERING SUPPORT REAR
211
SCREW SPARE WHEEL TO CROSS MEMBER, FOR USE WITH MERCEDES-BENZ BODY
211
SCREW BRACKET TO FRAME M 12X45
211
HEXAGON HEAD BOLT. SCREW BRACKET TO CROSS MEMBER
211
SCREW BRACKET TO SIDE MEMBER
211
SCREW , Replaced By: N304017010002
214
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
214
NUT , Replaced By: N910113012003
214
NUT AIR CLEANER ELEMENT
217
SPACER TUBE STRUT TO FRAME
217
SPACER TUBE , Replaced By: A6013210153
220
CONSOLE AT FRAME, 10/20 695199 50/60 695577 8 000001
223
SCREW END PIECE TO EXHAUST PIPE M 10X25
223
SCREW BRACKET TO SIDE MEMBER
223
SCREW , Replaced By: N304017010002
226
NUT AIR CLEANER ELEMENT
230
DRAG LINK
230
DRAG LINK
230
DRAG LINK , 10/20 615359-695198 50/60 615359-695576 ALSO INSTALLED ON 615344,615349.
230
DRAG LINK ,615358 EXCEPT FOR 615344,615349.
233
BOOT FIXED PART OF JOINT
233
BOOT FIXED PART OF JOINT
233
BOOT ,015018
236
NUT DRAG LINK TO LEVER, 10/20 615359-695198 50/60 615359-695576 ALSO INSTALLED ON 615344,615349.
236
NUT TORSION BAR TO FRAME
239
COTTER PINROCKINGER TYP 260 G140
239
COTTER PIN LEVER TO SUPPORT
242
GREASE NIPPLE
242
GREASE NIPPLE , Replaced By: N071412008102
245
JOINT TO BE SCREWED INTO DRAG LINK LEMFOERDER
248
BOOT
251
CLAMP CLAMP, ONE-HOLE
254
SCREW CLAMP TO DRAG LINK
257
NUT REINFORCEMENT TO BRACKET
257
NUT , Replaced By: N910113010003
260
NUT DRAG LINK TO LEVER,4 215305
263
COTTER PINROCKINGER TYP 260 G140
999
BOOT , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0003300885
999
BOOT , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0003301185
999
JOINT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0013300335
999
CLAMP , Replaced By: A4619955044
999
NEEDLE BEARING
999
PLUG , Replaced By: N000906016000
999
BUSHING ,582084
999
BOOT , Replaced By: A3144600396
999
BOOT STEERING JOINT, 10/20 695198 50/60 695576
999
DRAG LINK ,615358 EXCEPT FOR 615344,615349.
999
STEERING SHAFT ,4 373947, Replaced By: A3144601109, +002A0119815110
999
STEERING BRACKET AT FRAME, 10/20 695198 50/60 695576
999
STEERING COLUMN BRACKET STEERING COLUMN,4 373947
999
DRAG LINK , 10/20 615359-695198 50/60 615359-695576 ALSO INSTALLED ON 615344,615349.
999
BRACKET ,4 373946, Replaced By: A3144601130, +002A3224620023, +002A3124621150, +002A3214620165
999
STEERING SHAFT PLEASE REFER TO ADDITIONAL PARTS,4 373947
999
BRACKET STEERING COLUMN,4 373947
999
WASHER , Replaced By: A3224620023
999
RING ,007068, Replaced By: A3144620251, +001A0029970745
999
SEAL RING , Replaced By: A3144620360
999
RING STEERING NUT BEARING,007069 10/20 695198 50/60 695576
999
BOOT , Replaced By: A3144600396
999
SEAL RING
999
GROMMET , Replaced By: A3144600396
999
GROMMET STEERING COLUMN BRACKET COVERING, 10/20 695199 50/60 695577 8 0000014 2827078 000001-8 001702
999
BOOT , Replaced By: A3144620686
999
DRAG LINK , EXHAUST STOCK OF OLD PARTS FROM CHASSIS 695199 - 4 282707, Replaced By: A3164600805
999
DRAG LINK , EXHAUST STOCK OF OLD PARTS FROM CHASSIS 695199 - 4 282707, Replaced By: A3164600905
999
STEERG. WORM SECTOR SHAFT , Replaced By: A3214601111
999
COVER
999
STEERING BOX COVER , Replaced By: A3214600414, +001A0029900251
999
SCREW STEERING SHAFT TO STEERING M 8X42
999
NUT , Replaced By: A6743560226
