Поз.
Артикул
Описание
6
BOOT UNIVERSAL JOINT COVERING
6
BOOT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. P 235579, Replaced By: A6114620196
13
CONSOLE (STEERING BRACKET)
18
SCREW BRACKET TO FRAME SIDE MEMBER
21
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
25
SCREW STEERING TO STEERING BRACKET
28
LOCK WASHER FITTING TO BRACKET
28
LOCK WASHER BATTERY CABLE
31
LOCK WASHER CAB TO FRONT CONSOLE,4 444945
36
WASHER COMBINATION CYLINDER TO SLACK ADJUSTER
42
STEERING SHAFT ,214382
42
STEERING SHAFT
42
STEERING SHAFT ,144138214382
42
STEERING SHAFT ,144137
42
STEERING SHAFT ,214383 , P 000001
42
STEERING SHAFT ,144137
42
STEERING SHAFT ,214383
42
STEERING SHAFT
42
STEERING SHAFT , Replaced By: A6014600309
42
STEERING SHAFT , Replaced By: A6014620101
42
STEERING SHAFT , Replaced By: A6014600809
52
OIL TANK
58
NUT BATTERY MOUNTING
64
COVER
70
GASKET
70
SEAL RING
76
SPRINGMANN
82
WASHER
88
SCREW APPARATUS PLATE M 6X150
88
SCREW
92
FILTER
98
LOCK
106
BRACKET OIL TANK
106
BRACKET OIL TANK, 806686 P000001
114
CLAMP
114
CLAMP FROM AIR CLEANER TO HOT AIR INTAKE PIPE
118
BRACKET BRACKET TO CAB,899080
122
SCREW COVER PLATE TO COVER PLATE M 6 X 12
122
SCREW , Replaced By: N304017006018
130
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
146
HOSE80 MM, ORDER BY THE METER
154
CLAMP HOSE TO FITTING AND TO OIL TANK
154
CLAMP , Replaced By: N000000000667
154
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
154
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
162
PIPE , Replaced By: A0005516256
162
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
162
PIPE FROM OIL TANK TO PUMP,806685
162
PIPE FROM OIL TANK TO PUMP
178
UNION NUT LINE CONNECTION
186
GLAND LINE CONNECTION
194
PIPE FROM OIL TANK TO PUMP,806685
194
LINE FROM OIL TANK TO PUMP
202
HOSE FROM PUMP TO STEERING
202
LINE FROM PUMP TO STEERING,P 102664 P239048
202
HOSE FROM PUMP TO STEERING, P239048
202
HOSE FROM PUMP TO STEERING
202
HOSE FROM PUMP TO STEERING, P239048
202
HOSE FROM PUMP TO STEERING
202
LINE FROM PUMP TO STEERING,P 102664
202
LINE FROM PUMP TO STEERING,P 102664
202
HOSE FROM PUMP TO STEERING
202
LINE FROM PUMP TO STEERING,P 102664 P239048
202
LINE FROM PUMP TO STEERING,P 102664 P239048
216
NUT. UNION NUT LINE CONNECTION
218
CUTTING RING. GLAND LINE CONNECTION
226
HOSE FROM STEERING TO OIL TANK,806685
235
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
235
CLAMP HOSE TO FITTING AND TO OIL TANK
242
PIPE FROM STEERING TO OIL TANK
250
UNION NUT LINE CONNECTION, Replaced By: N000000006239
258
GLAND , Replaced By: A0019901967
258
SEAL CONE LINE CONNECTION
999
CONSOLE (STEERING BRACKET)
