Поз.
Артикул
Описание
5
SWITCH P.T.O. UNLOCKING
8
SWITCH (SAFETY MASTER SWITCH)
11
COVERING
11
COVERING , Replaced By: A3568202112
14
RELAY , Replaced By: A0035459605
14
RELAYA32/K6
14
RELAYA33, Replaced By: A0009822123
14
RELAYA33
14
RELAY , Replaced By: A0035459605
14
RELAY SECONDARY SWITCHBOARD K 99
17
DIODE ,K 182153
20
FUSE , Replaced By: N072581000304
29
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
29
PLUG , Replaced By: A0195450028
32
FLAT PIN BUSHING0.5-1.0 MM2
35
PIN BUSHING , Replaced By: A0075458226
38
FLAT PIN BUSHINGTO 002 545 92 26,1.5-2.5 MM 2
38
CONTACT SPRING , Replaced By: A0045455226
38
CONTACT SPRING0,5 - 1,0 MM2
41
PIN BUSHING HOUSING UNIPOLAR
44
PIN BUSHING HOUSING BIPOLAR
47
PLUG HOUSING BIPOLAR
50
PLUG HOUSING 4-POLE
53
PLUG HOUSING 10-POLE
59
PIN BUSHING HOUSING 4-POLE
62
PIN BUSHING HOUSING 5-POLE
999
CABLE HARNESS , WHEN ORDERING CABLE HARNESSES STATE THE FOLLOWING: VEHICLE, IDENT. NO., INSTALLATION LOCATION/FUNCTION,AND/OR THE HARNESS NUMB ER ON THE HARNESS OR THE PART NUMBER
