Поз.
Артикул
Описание
8
CROSS MEMBER BATTERY/APPARATUS SUPPORT NO.3
8
CROSS MEMBER , Replaced By: A3853120015
16
CROSS MEMBERNO.3A
32
STRUT LEFT AND RIGHT
32
STRUT LEFT AND RIGHT
48
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
48
SCREW , Replaced By: A0029908201
56
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
56
NUT , Replaced By: N910113012003
64
CROSS MEMBER REAR SPRING FRONT BRACKET
72
REINFORCEMENT LEFT AND RIGHT
80
SCREW STRUT TO CROSS MEMBER M 10X25
80
SCREW , Replaced By: N304017010040
88
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
96
BRACKET TOP
104
BRACKET BOTTOM
112
ANGLE CROSS MEMBER
136
SCREW BRACKET TO FRAME M 12X35
139
SCREW MOUNTING TO CONSOLE M 14X35
139
SCREW , Replaced By: N308676014008
144
WASHER
146
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
146
WASHER , Replaced By: N000125015019
152
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
152
NUT , Replaced By: N910113012003
160
NUT , Replaced By: N910113014000
160
NUT STEERING SUPPORT TO FRAME
168
SCREW APPARATUS SUPPORT TO FRAME
168
SCREW , Replaced By: A9429901304
176
NUT STEERING SUPPORT TO FRAME
176
NUT , Replaced By: N910113014000
184
SCREW PROPELLER SHAFT BEARING TO CROSS MEMBER
192
HEXAGON NUT
192
NUT , Replaced By: N910113010002
200
HEXAGON HEAD BOLT. SCREW BRACKET TO CROSS MEMBER
200
SCREW , Replaced By: N308676012013
200
HEXAGON HEAD BOLT , Replaced By: A0029902704
200
SCREW BRACKET TO FRAME M 12X35
280
SCREW ANGLE TO CROSS MEMBER M 10X30
296
NUT , Replaced By: N910113010002
296
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
296
HEXAGON NUT
296
NUT , Replaced By: N910113012003
312
NUT , Replaced By: N910113012005
312
HEXAGON NUT. NUT SPRING BOLT
320
FRONT SPRING BRACKET STEERED AXLE,LEFT FRONT
320
FRONT SPRING BRACKET STEERED AXLE,RIGHT FRONT
336
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
336
SCREWM 16X18X38X60
344
SCREW SPRING BRACKET TO FRAME M16X85
344
SCREWM 16X18X63X85
352
SCREW MOUNTING TO CONSOLE M 14X55
352
SCREW , Replaced By: N000961018043
352
SCREWM 14X15X29X46
352
SCREW BRACKET TO SIDE MEMBER M 14X1.5X50,5 543914
352
SCREW , Replaced By: N308676012016
352
HEXAGON HEAD BOLT. SCREW REINFORCEMENT TO SIDE MEMBER M 12X55
352
SCREWM 18X18X33X55
352
SCREWM 18X18X23X45
352
SCREWM 14X15X35X52
352
SCREW SHOCK ABSORBER TO BOTTOM BRACKET M 16X85
352
SCREW MOUNTING TO SIDE MEMBER M 14X85
352
SCREW BEARING BRACKET TO STEERING COLUMN BRACKET
999
CROSS MEMBERNO.4
999
CROSS MEMBERNO.3
