Поз.
Артикул
Описание
484
CONSOLE CAB MOUNTING,FRONT
488
BOW CAB MOUNTING,FRONT
492
STRUT BUMPER,LEFT
492
STRUT BUMPER,RIGHT
494
WASHER SHOCK ABSORBER TO UPPER BEARING BRACKET
496
SCREW , Replaced By: A9429901304
496
SCREW APPARATUS SUPPORT TO FRAME
504
NUT , Replaced By: N910113014000
504
NUT STEERING SUPPORT TO FRAME
508
SCREWM 16X18X26X48
512
NUT , Replaced By: N910113016001
512
NUT CONSOLE TO SUPPORT
516
BRACKET LEFT BUFFER
516
BRACKET RIGHT BUFFER
520
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
524
WASHER SPARE WHEEL CARRIER
528
NUT , Replaced By: N910113014001
528
NUT BRACKET TO SIDE MEMBER
532
MOUNTING (RUBBER BUFFER)
536
SCREW , Replaced By: N304017008034
536
SCREW BRACKET TO CROSS CONNECTION STRUT
540
WASHER , Replaced By: N009021008213
540
WASHER BRACKET TO LEFT SIDE MEMBER
544
NUT , Replaced By: N913004008001
544
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
544
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
550
MOUNTING CAB SUSPENSION,FRONT RIGHT
556
SHIM MOUNTING TO CONSOLE
566
SCREW MOUNTING TO SIDE MEMBER M 14X85
570
SCREW MOUNTING TO CONSOLE,TO BRACKET,AND TO STRUT M 14X100
576
WASHER SPARE WHEEL CARRIER
584
NUT , Replaced By: N910113014000
584
NUT STEERING SUPPORT TO FRAME
604
LEVER (TILTING LEVER),CAB
608
BUSHING TILTING LEVER
608
BUSHING TILTING LEVER
612
BUFFER TILTING LEVER
616
BUSHING ON TOGGLE LEVER,FOR HYDRAULIC CYLINDER
660
MOUNTING CAB TILTING LEVER
664
SCREW END PIECE TO EXHAUST PIPE M 10X25
664
SCREW , Replaced By: N308676012012
664
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
664
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
666
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
666
LOCK WASHER FITTING TO BRACKET
999
NUT , Replaced By: N910113012003
999
LOCK PULL TO FASTENER
999
LOCK , Replaced By: N912002008003
999
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
999
RIVET REAR CROSS MEMBER 12X42 MM
999
WASHER
999
COTTER PIN LEVER TO ROD
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
CROSS MEMBERNO.2, 191,19610/50 5 160092 191205 018393 191604 962984 19620/60 5 018393
999
FRONT SPRING BRACKET FRONT, FROM IDENT NO. 5 025412 ALSO INSTALLED ON 5 022764,5 023094,5 023152,5 023194,5 023364,5 023395,5 023475,5 023522,5 023549,5 023744,5 023802,5 023818,5 023852,5 023985, 5 024133,5 024169,5 024185,5 024195,5 024585,5 024645,5 024660,5 024964,5 025014,5 025045,5 025054,5 025095,5 025131,5 025221.5 110917
999
FRONT SPRING BRACKET , Replaced By: A6203220103
999
STRUT LEFT AND RIGHT
999
CROSS MEMBERNO.3A
999
REPAIR KIT , Replaced By: A3879920003, +002A6208910017, +001A3638910023
999
RIVET BUSHING AND LEVER TO CAB
999
PIN PULL TO FASTENER
999
SCREW , Replaced By: A0029908201
999
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
