Поз.
Артикул
Описание
3
SCREW SUPPORT TO SIDE MEMBER M 14X45
3
SCREW CONSOLE TO SIDE MEMBER
3
HEXAGON HEAD BOLT , Replaced By: A0029902704
3
SCREW , Replaced By: N308676012013
3
SCREW , Replaced By: N308676014012
6
LOCK WASHER FITTING TO BRACKET
9
CONSOLE PEDESTAL
10
NUT STEERING SUPPORT TO FRAME
10
NUT , Replaced By: N910113014000
11
WASHER , Replaced By: N000125015019
11
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
18
STRUT BUMPER,RIGHT
18
STRUT BUMPER,LEFT
19
PLUG HOUSING 4-POLE, MODULE "V"
32
SPACER RING CONSOLE AND STRUT TO FRAME
42
MOUNTING RIGHT SIDE MEMBER
42
MOUNTING CAB, RIGHT
42
MOUNTING CAB,LEFT
42
MOUNTING RIGHT SIDE MEMBER
42
MOUNTING LEFT SIDE MEMBER
42
MOUNTING LEFT SIDE MEMBER
42
MOUNTING , Replaced By: A6558910320
42
MOUNTING , Replaced By: A6558910420
45
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
45
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
45
SPRING , Replaced By: A3878910551, +002A3638910617, +001N071412008200
45
SPRING CAB SUSPENSION,FRONT
48
BUSHING SPRING
51
GREASE NIPPLE FOR SPRING
54
MOUNTING CAB, RIGHT
54
MOUNTING CAB,LEFT
57
WASHER BEARING BRACKET
57
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
57
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
66
HEADLESS SETSCREW FOR SPRING
69
WASHER TORSION BAR TO BEARING BRACKET
69
WASHER TORSION BAR TO BEARING BRACKET, Replaced By: N007349017003
72
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
72
NUT COMBINATION CYLINDER TO BEARING BRACKET
75
LEVER (TILTING LEVER),CAB
75
LEVER (TILTING LEVER),CAB
75
LEVER (TILTING LEVER),CAB
75
LEVER , Replaced By: A3878912556, +002A6208910017
75
LEVER , Replaced By: A3878912856, +002A6208910017
75
LEVER , Replaced By: A3878912756, +002A6208910017
75
LEVER , Replaced By: A3878912556, +002A6208910017
75
LEVER , Replaced By: A3878912856, +002A6208910017
75
LEVER , Replaced By: A3878912756, +002A6208910017
75
LEVER , Replaced By: A3878912856, +002A6208910017
78
BUSHING TILTING LEVER
78
BUSHING TILTING LEVER
81
BUSHING ON TOGGLE LEVER,FOR HYDRAULIC CYLINDER
81
JOINT BEARING , Replaced By: A0019814631
81
JOINT BEARING , Replaced By: A0009817231
81
JOINT BEARING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6208910017
81
JOINT BEARING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6208910017
81
LOCK , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6208910017
84
LOCK , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6208910017
84
BUFFER TILTING LEVER
85
BUSHING TILTING LEVER
85
REPAIR KIT , Replaced By: A3879920003, +002A6208910017, +001A3638910023
87
MOUNTING ,5 178428, Replaced By: A6218900403, +001A6203100177
87
MOUNTING ,5 178428, Replaced By: A6218900503, +001A6203100177
87
MOUNTING STABILIZER TO CAB,RIGHT,4 493779
87
MOUNTING SPRING AND STABILIZER,LEFT
87
MOUNTING SPRING AND STABILIZER,RIGHT
87
MOUNTING STABILIZER TO CAB,LEFT,5 094188
88
PIN
90
BRACKET BUFFER
96
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
96
SCREW CONSOLE TO SIDE MEMBER
96
SCREW , Replaced By: N308676012026
102
NUT SUPPORT TO SIDE MEMBER
105
BUFFER , FIRST EXHAUST STOCK OF OLD PARTS,10/20 UP TO IDENT NO. 4 253140,50/60 UP TO IDENT NO. 4 257207, Replaced By: A3348910072
105
MOUNTING (RUBBER BUFFER)
108
SCREW BRACKET TO CROSS CONNECTION STRUT
108
SCREW , Replaced By: N304017008034
111
WASHER , Replaced By: N009021008213
111
WASHER BRACKET TO LEFT SIDE MEMBER
114
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
114
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
114
NUT , Replaced By: N913004008001
117
STABILIZER , Replaced By: A3878900404
117
STABILIZER , Replaced By: A6528900104
117
STABILIZER CAB SUSPENSION,FRONT,5 094188
117
STABILIZER CAB SUSPENSION,FRONT
120
GREASE NIPPLE FOR SPRING
126
JOINT BEARING
126
JOINT BEARING
126
JOINT BEARING , Replaced By: A0009817231
126
JOINT BEARING , Replaced By: A0009817331
126
JOINT BEARING , Replaced By: A0019814631
126
JOINT BEARING , Replaced By: A0009817231
127
SCREW PLUG STABILIZER
129
CONSOLE CAB SUSPENSION,FRONT LEFT
129
CONSOLE CAB SUSPENSION,FRONT RIGHT
129
CONSOLE , Replaced By: A6208910631
129
CONSOLE , Replaced By: A6208910731
132
SCREW ,5 903514, Replaced By: N000960012353
132
SCREW , Replaced By: N308676012015
132
SCREW LEFT AND RIGHT CONSOLES TO CAB
132
SCREW TORSION BAR TO SHACKLE,5 903514
135
SCREW LEFT AND RIGHT CONSOLES TO CAB M 12X30
138
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
138
SCREW , Replaced By: N308676014020
141
LOCK WASHER FITTING TO BRACKET
144
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
147
WASHER LEFT AND RIGHT CONSOLES TO CAB
150
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
150
SCREW , Replaced By: N308676012031
150
SCREW , Replaced By: N308676012011
153
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
153
SCREW BRACKET TO CAB CONSOLE,K 035197
162
WASHER SPARE WHEEL CARRIER
162
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
162
WASHER , Replaced By: N000125015019
165
LOCK WASHER FITTING TO BRACKET
168
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
171
NUT BRACKET TO SIDE MEMBER
171
NUT , Replaced By: N910113014001
173
WASHER BRACKET TO SIDE MEMBER,5 703114
178
SCREW STABILIZER TO BEARING
180
NUT BRACKET TO SIDE MEMBER
180
NUT , Replaced By: N910113014001
183
WASHER STABILIZER TO BEARING
186
SCREW , Replaced By: N000961014148
186
SCREW BRACKET TO CAB CONSOLE,K 035197
186
SCREW FRONT SPRING REAR BRACKET TO SIDE MEMBER M 14X1.5X75
187
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
187
WASHER BRACKET TO SIDE MEMBER,5 703114
187
WASHER , Replaced By: N000125015019
188
SCREW , Replaced By: N000961014064
188
SCREW BRACKET TO SIDE MEMBER
189
SCREW BRACKET TO CROSS CONNECTION STRUT
189
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
189
SCREW , Replaced By: N304017008034
192
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
192
NUT , Replaced By: N913004008001
192
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
195
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
195
SHOCK ABSORBER CAB SUSPENSION,REAR,4 330046
195
SHOCK ABSORBER CAB SUSPENSION,REAR,4 330046
195
SHOCK ABSORBER , Replaced By: A0008911805
198
RUBBER MOUNTING , Replaced By: A0008910001
198
RUBBER MOUNTING , Replaced By: A0008910501
198
RUBBER MOUNTING
198
RUBBER MOUNTING ,4 330046
201
BUSHING ,4 330046
201
BUSHING
201
BUSHING , Replaced By: A0008910117
201
BUSHING , Replaced By: A0008910617
204
WASHER VIBRATION ABSORBER TO BEARING AND TO CAB
204
WASHER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6203170176
204
WASHER SHOCK ABSORBER TO CAB,4 172502 10/20 UP TO IDENT NO. 4 253140,50/60 UP TO IDENT NO. 4 257207
204
WASHER SHOCK ABSORBER TO CAB,4 172501
207
WASHER
207
WASHER , Replaced By: N000125013008
207
WASHER , Replaced By: N000125010532
207
WASHER RADIATOR TO RUBBER MOUNTING
210
NUT , Replaced By: N910113010002
210
HEXAGON NUT
210
NUT SUPPORT TO SIDE MEMBER
295
MOUNTING CAB TILTING LEVER
295
MOUNTING , MODEL 416,417 FOR USE WITH MEDIUM-LENGTH MERCEDES-BENZ CAB FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 837892, Replaced By: A6208901603
295
MOUNTING , Replaced By: A3878913220
298
SCREW END PIECE TO EXHAUST PIPE M 10X25
301
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
304
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
304
SCREW , Replaced By: N308676012012
307
LOCK WASHER FITTING TO BRACKET
310
SHIM MOUNTING TO CONSOLE
310
SHIM , Replaced By: A3878910498
310
SHIM , Replaced By: A3878910498
313
DOWEL PIN MOUNTING TO CONSOLE
316
SCREW MOUNTING TO CONSOLE M 14X35
316
SCREW , Replaced By: N308676014008
317
SCREW , Replaced By: N308676014003
317
HEXAGON HEAD BOLT. SCREW ENGINE MOUNTING TO SUPPORT,ON CLUTCH END M 14X30
317
SCREW STEERING SUPPORT TO FRAME M 14X55
319
SCREW BRACKET TO SUPPORT
319
SCREW HYDRAULIC CYLINDER BEARING BRACKET TO FRAME M 16X25
319
SCREW CONSOLE TO FRAME
319
SCREW , Replaced By: N308676016020
322
WASHER SPARE WHEEL CARRIER
325
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
326
LOCK WASHERROCKINGER TYP 59 G140,59 G150
328
NUT CAB ON CONSOLE AT FRAME
328
NUT STEERING SUPPORT TO FRAME
328
NUT , Replaced By: N910113014000
611
BUFFER (HOLLOW RUBBER SPRING),CAB
614
FLANGE HOLLOW RUBBER SPRING
617
BUSHING HOLLOW RUBBER SPRING
620
WASHER HOLLOW RUBBER SPRING TO CAB,5 956657
620
WASHER , Replaced By: A3878912210
620
WASHER , Replaced By: A4432610076
623
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
626
SCREW BRACKET TO SIDE MEMBER
626
SCREW BRACKET TO FRAME SIDE MEMBER
626
SCREW , Replaced By: N304017010002
999
PUMP , Replaced By: A0005536801
