Поз.
Артикул
Описание
14
SUPPORT FAN DRIVE
17
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
17
SCREW , Replaced By: N910105010009
17
SCREWM 10X20
20
WASHER BRACKET TO BRACKET
23
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
33
CLAMP CONNECTION OF CHARGING AIR PIPES
34
CLAMP
36
CLAMP CONNECTION OF CHARGING AIR PIPES
37
CLAMP CONNECTION OF CHARGING AIR PIPES
38
CLAMP. STRAP CONNECTION OF CHARGING AIR PIPES
42
STRAP CONNECTION OF CHARGING AIR PIPES
46
RUBBER MOUNTING FASTENING OF LINES AND HOSES
48
RUBBER MOUNTING AIR CLEANER TO SUBSTRUCTURE
48
RUBBER MOUNTINGM8
54
ANGLE FASTENING OF LINES AND HOSES
60
ANGLE FASTENING OF LINES AND HOSES
62
BRACKET
63
BRACKET FASTENING OF LINES AND HOSES
63
BRACKET PIPE ELBOW TO SUBSTRUCTURE
64
BRACKET FASTENING OF LINES AND HOSES
66
BRACKET FASTENING OF LINES AND HOSES
66
BRACKET AT TRANSMISSION
69
BRACKET FASTENING OF LINES AND HOSES
72
SPACER WASHER
75
SCREW CLAMP TO EXHAUST PIPE
75
SCREW BRACKET MOUNTING M6 X 20
75
HEXAGON HEAD BOLT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER M14X1.5X40
75
HEXAGON HEAD BOLT. SCREW TIMING CASE COVER TO TIMING CASE, FROM ENGINE 978,979 331711 YEAR OF MANUFACTURE 1994
75
SCREW BRACKET TO SIDE MEMBER M8X20
75
SCREW. HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X40
75
SCREW BRACKET TO CAB REAR PANEL M 8X20
76
SCREW BRACKET TO DISC WHEEL M 10X16,D 315832
77
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
78
WASHER BRACKET TO CAB REAR PANEL
78
WASHER TRANSMISSION TO INTERMEDIATE RING
78
WASHER COLD START SYSTEM TO BRACKET
78
WASHER , Replaced By: N009021006208
78
WASHER , Replaced By: N009021008213
78
WASHER BRACKET TO LEFT SIDE MEMBER
79
WASHER BRACKET TO COVERING
80
NUTM10
81
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
81
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
81
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
81
NUT STRAP TO BRACKET
81
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
81
NUT HORN TO BRACKET M8
81
NUTM8
82
HEXAGON NUT
999
LINE CHARGING AIR LINE
999
LINE CHARGING AIR LINE
999
LINE CHARGING AIR LINE
999
LINE CHARGING AIR LINE
999
LINE CHARGING AIR LINE
999
LINE CHARGING AIR LINE
999
LINE CHARGING AIR LINE
999
LINE CHARGING AIR LINE
999
AIR INTAKE PIPE CHARGING AIR LINE
