Поз.
Артикул
Описание
5
VALVE PRESSURE CONTROL VALVE ABS
11
SCREWM 8X90
14
NUT HORN TO BRACKET M8
17
SCREW SPEED SENSOR TO REAR AXLE
17
SCREW , Replaced By: N910143008000
20
NUT HORN TO BRACKET M8
23
REDUNDANCY VALVE. VALVE (RELAY VALVE)
29
SCREW. UNION SCREW LINE CONNECTION
32
MODULATOR TRAILING AXLE
32
AXLE MODULATOR REAR AXLE VOSS 232
32
AXLE MODULATOR , Replaced By: A0004291524
32
AXLE MODULATOR REAR AXLE EPB, REPAIR IMPOSSIBLE
34
T-FITTING AIR RESERVOIR, UP TO IDENT NO. WEB 105308 EXCEPT FOR 104831-104930,104931-105130,105261,105268-105295,105307. ALSO INSTALLED IN 105317,105318,105324,105382,105388. UP TO IDENT NO.VF9 300288 EXCEPT FOR 300046,300282-300284.
35
SCREW PLUG SOLENOID VALVE M16
35
SCREW. UNION SCREW , Replaced By: A0009973734
35
SCREW. UNION SCREW LINE CONNECTION
35
SCREW. UNION SCREW LINE CONNECTION
38
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X35
41
NUT HORN TO BRACKET M8
44
BRACKET AXLE MODULATOR
