Главная
›
Mercedes
›
BUS
›
O 530 N3 LANG EURO 3
›
628.147
›
68 COVERING AND LINING
›
450 ENGINE COMPARTMENT ENCLOSURE
Mercedes N910001004105 - Клипса
O 530 N3 LANG EURO 3 628.147
68 COVERING AND LINING - 450 ENGINE COMPARTMENT ENCLOSURE
Поз.
Артикул
Описание
5
A6286831308
COVERING LEFT FRONT
6
A6286830114
BRACKET
7
A6286830208
COVERING LEFT FRONT
10
N910112005000
HEXAGON NUT. NUT ELECTRIC CABLE TO ALTERNATOR
11
A6286830068
MOUNTING
12
N910105005000
HEXAGON HEAD BOLT. SCREW BATTERY MOUNTING M5X12
13
A3565040084
SHIM RADIATOR TO SUBSTRUCTURE
15
A6286830508
COVERING LEFT REAR
19
A6286831508
COVERING RIGHT CENTRAL,REAR
21
A6286800614
BRACKET
21
A6286800814
BRACKET
22
N910105006002
HEXAGON HEAD BOLT
23
A6286834508
COVERING RIGHT REAR
23
A6286831408
COVERING RIGHT REAR
23
A6286832708
COVER RIGHT REAR
27
A0009840764
MOUNTING PLATE. RETAINING CAM
28
A0009844756
WASHER , Replaced By: A0009844256
30
A6286832135
ANGLE
33
A0009846436
LOCKING PIN. GUIDE
36
N910105006008
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
39
A0049941645
LOCK NUT. SPRING NUT MOUNTING PARTS
39
A0049941745
LOCK NUT. SPRING NUT STEP TO ENTRANCE
45
A6286830223
PLATE
50
A6286830188
EDGE GUARD SECTION
53
N910105006006
SCREW BRACKET AND CLAMP M6X20
56
A6286830714
BRACKET
58
A6286009414
BRACKET
62
A6286830214
BRACKET
65
N910001004105
RIVET LOCKING LEVER TO BATTERY/APPARATUS SUPPORT
68
A6286830314
BRACKET
71
N000000003738
WASHER4MM
