Поз.
Артикул
Описание
26
OIL COOLER FAN DRIVE
27
VALVE
27
VALVE , Replaced By: A6285500555
28
VALVE , Replaced By: A0005508455
28
VALVE
53
PIPE LINE
54
SEAL RING18X1.5
55
PIPE LINE ON DELIVERY SIDE
56
SEAL RING18X1.5
59
PIPE LINE FROM FAN DRIVE TO OIL COOLER
60
SEAL25,3 X 2,4
61
PIPE LINE OIL RETURN
62
SEAL BLEED CONNECTION TO RESERVOIR 32X2MM
63
SCREW PLUG FUEL TANK
63
SCREW PLUG, FILLINGM14X1,5
64
SEAL RINGTO 000 553 03 05,000 553 18 05,
65
HOUSING
68
PIPE LINE OIL RETURN
69
SEAL BLEED CONNECTION TO RESERVOIR 32X2MM
98
PIPE LINE FILTER BOWL
105
PLASTIC PIPE AERATION, ORDER BY THE METER
106
BANJO UNION COMPRESSED-AIR-LINE PLUG-CONNECTION
107
DOUBLE FITTING BETWEEN THE LINES
110
BANJO BOLT. HOLLOW SCREW
112
SEAL RING CHECK VALVE,CONNECTION "1",4 704213
223
SCREW , Replaced By: N910143008002
226
SCREW SHIFT LEVER TO BRACKET M8X30
