Поз.
Артикул
Описание
10
RADIATOR , Replaced By: A6525016401
10
RADIATOR , Replaced By: A6525015201
10
RADIATOR , Replaced By: A6525015201
10
RADIATOR
20
SUPPORT RADIATOR
30
SCREW CONSOLE TO SIDE MEMBER
40
NUT SUPPORT TO SIDE MEMBER
50
BEARING TO BE MOUNTED ON THE LEFT
60
SCREW , Replaced By: N304017010028
60
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
70
WASHER RADIATOR TO RUBBER MOUNTING
70
WASHER , Replaced By: N000125010532
80
FAN SHROUD RADIATOR
90
BOOT FAN SHROUD TO FAN RING
100
HOSE FROM RADIATOR TO THERMOSTAT
100
HOSE FROM RADIATOR TO THERMOSTAT
120
HOSE FROM RADIATOR OUTLET TO WATER PUMP
280
SCREW LEVER TO ENGINE CONTROL SHAFT
280
SCREW , Replaced By: N910105006023
999
FAN SHROUD
999
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
999
BRACKET CHARGING AIR INTERCOOLER TO RADIATOR
999
BRACKET CHARGING AIR INTERCOOLER,RIGHT BOTTOM
999
FAN SHROUD RADIATOR
999
RADIATOR , Replaced By: A6525016901
999
RADIATOR WITH SCREW FITTING
999
RADIATOR , Replaced By: A6525014201
999
HOSE FROM RADIATOR TO THERMOSTAT
999
SCREW AT FILTER BRACKET
