Поз.
Артикул
Описание
8
EXHAUST MUFFLER
11
CONNECTOR FROM CONNECTOR TO EXHAUST MUFFLER
16
BRACKET TAIL PIPE
24
CLAMP EXHAUST PIPE TO BRACKET
32
CLAMP , Replaced By: N071555090502
32
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
40
SCREW , Replaced By: N304017010002
40
SCREW BRACKET TO SIDE MEMBER
40
SCREW BRACKET TO SIDE MEMBER
48
NUT , Replaced By: N910113010000
48
NUT STRAP TO BRACKET
48
NUT STRAP TO BRACKET
56
END PIECE BEHIND CAB,UPWARD
56
END PIECE BEHIND CAB,UPWARD
56
END PIECE BEHIND CAB,UPWARD
56
END PIECE EXHAUST PIPE
64
FLAP (RAIN DEFLECTOR)
72
CLAMP , Replaced By: A4374920440
72
CLAMP HEAT SHIELD TO TAILPIPE
80
PROTECTIVE PLATE (HEAT SHIELD)
88
BASE PLATE HEAT SHIELD TO TAILPIPE
96
CLAMP , Replaced By: A4374920440
96
CLAMP HEAT SHIELD TO TAILPIPE
104
SCREW , Replaced By: N304017008034
104
SCREW BRACKET TO CROSS CONNECTION STRUT
120
PROTECTIVE PLATE (HEAT SHIELD)
128
SCREW , Replaced By: N304017010002
128
SCREW BRACKET TO SIDE MEMBER
136
NUT , Replaced By: N910113010000
136
NUT STRAP TO BRACKET
144
BRACKET TAIL PIPE
152
CLAMP , Replaced By: A4374920440
152
CLAMP HEAT SHIELD TO TAILPIPE
160
SCREW , Replaced By: N304017008034
160
SCREW BRACKET TO CROSS CONNECTION STRUT
160
SCREW BRACKET TO CROSS CONNECTION STRUT
168
NUT , Replaced By: N913004008001
168
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
168
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
176
BRACKET TAIL PIPE
184
BRACKET TAIL PIPE
192
SCREW , Replaced By: N304017010002
192
SCREW BRACKET TO SIDE MEMBER
192
SCREW END PIECE TO EXHAUST PIPE M 10X25
200
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
208
NUT , Replaced By: N910113010000
208
NUT STRAP TO BRACKET
216
NUT , Replaced By: N910113014001
216
NUT BRACKET TO SIDE MEMBER
224
BRACKET (STRUT),FROM TAIL PIPE TO SIDE MEMBER
232
BRACKET (STRUT),FROM TAIL PIPE TO SIDE MEMBER
240
SCREW BRACKET TO SIDE MEMBER
248
WASHER BRACKET TO SIDE MEMBER
256
NUT , Replaced By: N910113014001
256
NUT BRACKET TO SIDE MEMBER
264
CLAMP EXHAUST PIPE TO BRACKET
272
SCREW , Replaced By: N304017010002
272
SCREW BRACKET TO SIDE MEMBER
272
SCREW BRACKET TO SIDE MEMBER
280
NUT , Replaced By: N910113010000
280
NUT STRAP TO BRACKET
280
NUT STRAP TO BRACKET
999
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
999
NUT CHECK VALVE TO AIR RESERVOIR
999
SCREW , Replaced By: N304017008027
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125008443
999
PROTECTIVE PLATE (HEAT SHIELD)
999
BRACKET AIR RESERVOIR TO APPARATUS SUPPORT
999
END PIECE TAIL PIPE,FRONT,5 758826
999
REAR EXHAUST PIPE
999
END PIECE
999
END PIECE
999
BRACKET (STRUT),FROM TAIL PIPE TO SIDE MEMBER
999
EXHAUST PIPE FRONT EXHAUST PIPE
999
PROTECTIVE PLATE (HEAT SHIELD)
999
CONNECTOR BOTTOM CENTRAL
999
END PIECE
999
REAR EXHAUST PIPE TAIL PIPE,FRONT
999
PROTECTIVE PLATE (HEAT SHIELD)
999
END PIECE EXHAUST MUFFLER,LEFT REAR
999
SUPPORT TAIL PIPE TO SIDE MEMBER
999
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
