Поз.
Артикул
Описание
10
HOSE FROM EXPANSION TANK TO WATER PUMP
10
HOSE FROM EXPANSION TANK TO WATER PUMP
10
HOSE FROM EXPANSION TANK TO WATER PUMP, 5 721797
10
HOSE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6555062835
10
HOSE FROM EXPANSION TANK TO WATER PUMP, 5 721796
10
HOSE FROM EXPANSION TANK TO WATER PUMP
10
HOSE FROM EXPANSION TANK TO WATER PUMP
20
SEPARATOR (BUBBLE SEPARATOR)
30
BRACKET SEPARATOR TO BRACKET
40
SCREW COVER PLATE TO BRACKET
50
NUT PUMP TO BRACKET
50
NUT , Replaced By: N913004006001
60
HOSE FROM BUBBLE SEPARATOR TO HEATING PIPE 18X27 MM, ORDER BY THE METER
80
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
80
CLAMP , Replaced By: N000000000667
90
HOSE FROM CHECK VALVE TO PIPE LINE
100
VALVE CHECK VALVE
100
VALVE , Replaced By: A0008352872
110
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
110
CLAMP , Replaced By: N000000000667
120
LINE FROM ENGINE TO EXPANSION TANK
140
LINE FROM ENGINE TO EXPANSION TANK,5 944085
140
LINE FROM ENGINE TO EXPANSION TANK,5 944085
140
LINE FROM ENGINE TO EXPANSION TANK,5 944084
150
HOSE FEED LINE LEADING TO CAB
150
HOSE FEED LINE LEADING TO CAB
150
HOSE FEED LINE LEADING TO CAB
150
HOSE , Replaced By: A6555061535
160
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
160
CLAMP , Replaced By: N000000000667
170
LINE FEED LINE TO ENGINE, 5 525562
170
FLANGE FEED LINE TO ENGINE
170
FLANGE FEED LINE TO ENGINE, 5 525562
170
FLANGE FEED LINE TO ENGINE, 5 525562
180
HOSE FROM FLANGE TO VALVE, 5 525562
180
HOSE FROM FLANGE TO VALVE, 5 525562
180
HOSE FROM FLANGE TO VALVE, 5 525562
180
HOSE FROM FLANGE TO VALVE, 5 525562
190
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
190
CLAMP , Replaced By: N000000000667
200
VALVE (SOLENOID VALVE),5 762454
220
BRACKET SOLENOID VALVE
230
CLAMP
230
CLAMP
230
CLAMP , Replaced By: N000000000670
240
SCREW SOLENOID VALVE TO BRACKET
250
NUT BRACKET TO SIDE MEMBER
260
HOSE FROM VALVE TO FEED LINE,K 004002
260
HOSE FROM VALVE TO FEED LINE
260
HOSE , Replaced By: A3098321023
290
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
290
CLAMP , Replaced By: N000000000667
300
LINE HEATING FEED,K 004002
300
LINE HEATING FEED
300
LINE HEATING FEED
300
LINE , Replaced By: A6525002972
300
LINE HEATING FEED
300
LINE HEATING FEED
330
BRACKET FEED LINE
340
SCREW BRACKET TO SIDE MEMBER M 12X40
340
SCREW PIPE CLAMP
340
SCREW , Replaced By: N304017008021
350
NUT END PIECE TO EXHAUST PIPE
350
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
350
NUT , Replaced By: N913004008001
360
CLAMP FEED LINE TO THERMOSTAT
370
SCREW COVER PLATE TO BRACKET
370
SCREW REAR EXHAUST PIPE TO MUFFLER
370
SCREW END PIECE TO EXHAUST PIPE M 10X25
380
NUT PUMP TO BRACKET
380
NUT , Replaced By: N913004006001
380
NUT STRAP TO BRACKET
380
NUT , Replaced By: N910113010000
390
CLAMP FEED LINE TO THERMOSTAT
400
SCREW COVER PLATE TO BRACKET
410
NUT PUMP TO BRACKET
410
NUT , Replaced By: N913004006001
420
LINE HEATING AND BREATHING
440
HOSE FROM HEATING PIPE AT ENGINE TO HEATING PIPE AT RADIATOR
440
HOSE FROM HEATING PIPE AT ENGINE TO HEATING PIPE AT RADIATOR
450
HOSE FEED LINE TO RADIATOR,5 944085
450
HOSE FEED LINE TO RADIATOR,5 944085
470
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
470
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
470
CLAMP , Replaced By: N000000000667
500
SPACER TUBE BREATHER LINE TO SIDE MEMBER
500
SPACER TUBE BREATHER LINE TO SIDE MEMBER
510
CLAMP FEED LINE TO THERMOSTAT
520
SCREW COVER PLATE TO BRACKET
530
SCREW FRONT AXLE REGULATING SOLENOID VALVE
530
SCREW FRONT AXLE REGULATING SOLENOID VALVE
530
SCREW , Replaced By: N304014008007
540
NUT PUMP TO BRACKET
540
NUT , Replaced By: N913004006001
550
CLAMP FEED LINE TO THERMOSTAT
560
SCREW COVER PLATE TO BRACKET
570
NUT PUMP TO BRACKET
570
NUT , Replaced By: N913004006001
590
FLANGE HEATING CONNECTION LOCK
600
GASKET HEATING PIPE TO ENGINE
610
SCREW PIPE CLAMP
610
SCREW , Replaced By: N304017008021
999
BRACKET BRACKET TO ENGINE,REAR
999
LINE HEATING AND BREATHING
999
LINE (HEATING PIPE) FROM ENGINE TO HEATING PIPE AT RADIATOR
999
LINE HEATING AND BREATHING,5 549076
999
LINE (HEATING PIPE) FROM ENGINE TO HEATING PIPE AT RADIATOR
999
BRACKET ,K 125624
999
BRACKET FEED LINE,K 004003
999
LINE HEATING AND BREATHING
999
BREATHER PIPE FROM ENGINE TO EXPANSION TANK
999
LINE HEATING AND BREATHING
999
LINE (HEATING PIPE) FROM ENGINE TO HEATING PIPE AT RADIATOR,K 244830
999
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
999
BRACKET , Replaced By: A6764760036
999
BRACKET , Replaced By: A6162950440
999
BRACKET HEATING PIPE TO OIL COOLER
999
LINE (HEATING PIPE) FROM ENGINE TO HEATING PIPE AT RADIATOR
999
LINE (HEATING PIPE) FROM ENGINE TO HEATING PIPE AT RADIATOR
999
BRACKET FEED LINE TO THERMOSTAT
