Поз.
Артикул
Описание
277
OIL PAN
286
THREADED INSERT
286
THREADED INSERT OIL FILLER PIPE
288
STUD FILTER HOUSING TO CONVERTER HOUSING M 8X12,005160
290
SEAL RING BATTERY MASTER SWITCH
300
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
302
SCREW BEARING BRACKET TO TRANSMISSION
306
SEAL RING LINE CONNECTION
308
THREADED CHUCK OIL PAN,8500016-017213
317
SEAL RING LINE CONNECTION
322
SCREW PLUG OIL PAN,8500016-017213
324
SEAL RING TEMPERATURE GAUGE SENDER UNIT
326
THREADED INSERT TRANSMISSION CASE FRONT PART M 18X18
327
SCREW PLUG
328
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
329
THREADED INSERT REPAIR SIZE, TO BE ADAPTED DURING ASSEMBLY
330
GUIDE TUBE
335
GASKET OIL PAN,LEFT
335
GASKET , Replaced By: A3550140122
335
GASKET , Replaced By: A3260140921, +001A3550140022
340
GASKET OIL PAN,RIGHT
340
GASKET , Replaced By: A3550140022
340
GASKET , Replaced By: A3260140821, +001A3550140122
346
GASKET OIL PAN
348
OIL PAN OIL PAN
348
GASKET KIT , Replaced By: A3550100027
350
COVERING STARTING CABLE
351
WASHER EXHAUST MUFFLER TO STRAP
351
WASHER , Replaced By: N000125008443
356
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
368
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
368
SCREW , Replaced By: N304017008027
373
BRACKET ,9501677
376
BRACKET , Replaced By: A3462030140
376
BRACKET
378
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
382
NUT
388
GASKET
394
FILTER BREATHER,OIL PAN
396
HOSE , FROM ENGINE 017706 ALSO INSTALLED ON 015839,015887,015888,015993,015994,015997,016043,016115,016215,016328,016365,016463,016503,016544, 016741.
398
CLAMP , Replaced By: N000000000671
398
LOOM TIE , Replaced By: N916017040000
398
CLAMP
401
BRACKET BREATHER PIPE TO OIL PAN, 910,914,915 UP TO ENGINE 043950 ALSO INSTALLED ON 043994,043999,SEE FOOTNOTE 59
406
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
411
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
411
SCREW , Replaced By: N304014008001
416
GASKET. SEAL , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3559970149
416
GASKET , Replaced By: N917003040006
416
GASKET OUTLET TO ENGINE
420
FLANGE ,010589
425
THREADED INSERT OIL FILLER PIPE
456
BEARING BRACKET , SEE GROUP 07
461
OIL FILLER NECK943 MM
465
CLAMP
467
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
467
SCREW , Replaced By: N304017008016
469
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
471
OIL FILLER NECK , 057636
476
GASKETTO 352 010 01 68
476
SEALING RING. SEAL RING , 057635
481
CAP WITH OIL DIPSTICK 1212 MM,009825
482
OIL DIPSTICK , 057636
482
CAP , 057635, Replaced By: A3550100972, +001A3550101264, +001A3520100168
483
CAP , Replaced By: A0000180702
483
GASKETTO 352 010 01 68
484
CAP OIL REFILLING
485
GASKET
485
GASKET , Replaced By: A1020180380
485
GASKET , Replaced By: A1020180080
486
GASKET. SEAL , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3559970149
486
GASKET , Replaced By: N917003040006
486
GASKET OUTLET TO ENGINE
487
SCREW REAR EXHAUST PIPE TO MUFFLER
488
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
489
NUT BATTERY CABLE
489
NUT BRACKET TO SUPPORT AND TO END PIECE
491
GASKET. SEAL , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3559970149
491
GASKET , Replaced By: N917003040006
491
GASKET OUTLET TO ENGINE
496
SCREWTO 000 431 94 14,000 431 96 14
497
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
497
SCREW , Replaced By: N304017008016
498
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
499
NUT , Replaced By: N304032008006
501
BRACKET
506
BRACKET ,009826
511
LOCK WASHER FITTING TO BRACKET
516
SCREW BRACKET TO TRANSMISSION
516
SCREW , Replaced By: N308676012038
521
CLAMP
523
NUT , Replaced By: N304032008006
526
BRACKET
531
STUD SHIFT CASE TO 352 260 12 14,352 260 17 14,4 473926 FROM IDENT NO. SEE MICROFICHE MODEL 714.0 FROM IDENT NO. SEE MICROFICHE MODEL 714.0
531
STUD
536
STUD SECONDARY PUMP
538
SCREW PIPE CLAMP
538
SCREW , Replaced By: N304017008021
541
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
546
WASHER EXHAUST MUFFLER TO STRAP
546
WASHER , Replaced By: N000125008443
551
NUT , Replaced By: N304032008006
552
CLAMP
553
SCREW VALVE TO BRACKET M 8X55
553
SCREW , Replaced By: N304017008043
554
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
555
NUT , Replaced By: N304032008006
999
SEAL. GASKET , Replaced By: A3661880880
999
GASKET , Replaced By: N917003026003
999
SEAL RING TO 18-MM-DIA. COMPRESSED AIR LINES
999
SEAL RING
999
SEAL RING FUEL LINE TO FEED PUMP
999
SEAL RING , Replaced By: N007603038101
999
SEAL RING OIL COOLER CONNECTION
999
SEAL RING OIL FILLING AND OIL DRAIN
999
SEAL RING OIL FILLING AND OIL DRAIN
999
SEAL RING 2/2-WAY VALVE,CONNECTION: "20"
999
SEAL RING FROM POWER STEERING PUMP AT ENGINE TO CUT-IN VALVE
999
SEAL RING LOCKING VALVE 20X24
999
SEAL RING SWITCH TO CASE COVER
999
SEAL RINGTO 006 997 00 72
999
SEAL RING FUEL LINE TO FEED PUMP
999
SEAL RING BOTTOM
999
SEAL RING VALVE,CONNECTION "10"
999
SEAL RING BRAKE CYLINDER STROKE INDICATOR
999
SEAL RING BRACKET TO CYLINDER HEAD
999
SEAL RING SCREW PLUG
999
SEAL RING OIL PAN TO TRANSMISSION
999
SEAL RINGTO 000 429 24 30
999
RADIAL SEAL RING
999
STUD BOLT , SEE GROUP 14, TABLE 10, FIG. NO. 20, Replaced By: A3269900019
999
STUD , SEE GROUP 07
999
STUD
999
SCREW , Replaced By: N304017008021
999
GASKET INJECTION PUMP
999
GASKET CYLINDER HEAD COVER
999
GASKET CONNECTOR TO CYLINDER CRANKCASE
999
GASKET OIL FILTER TO CYLINDER CRANKCASE
999
GASKET OIL COOLER TO OIL FILTER
999
SEALING FLANGE EXHAUST MANIFOLD TO CYLINDER HEAD
999
PLUG , Replaced By: A3469970135
999
GASKET THREE-HOLE
999
SEALING FLANGE , Replaced By: A3451420080
999
GASKET CYLINDER SIDE COVER
999
GASKET TIMING CASE COVER
999
CYLINDER SIDE COVER
999
OIL PAN ,011275, Replaced By: A3550100113, +001A3550180140, +027N000931008266
999
COVER
999
OIL PAN ,011274, Replaced By: A3550100113, +001A3550180140, +027N000931008266
999
GASKET EXHAUST MANIFOLD TO CYLINDER HEAD
999
EXPANSION PLUG , NO LONGER AVAILABLE INDIVIDUALLY
999
SCREW PLUG ,017214 ONLY FOR REPAIRS ON 3260101028,3260101128,3260101228,3260101328,3260101428,3260101728 OIL PANS
999
GASKET KIT ENGINE CHECK
999
GASKET KIT ENGINE GENERAL OVERHAUL
999
GASKET KIT , Replaced By: A3265860190
999
PROTECTIVE PLATE BOTTOM,015296
999
GASKET
999
GASKET , Replaced By: A3602030280
999
PIPE SOCKET ,009825
999
PIPE SOCKET ,009825
999
GASKET , Replaced By: A3551840680
999
BRACKET , NOT USED
999
ANGLE ,015295
999
GASKET INTAKE MANIFOLD
999
GASKET , Replaced By: A3660770080
999
VALVE GUIDE , FROM ENGINE 7500242-9500862 EXCEPT FOR, SEE FOOTN. 102, Replaced By: A3260531830, +002A3220530125, +002A3260530160
999
VALVE GUIDE , FROM ENGINE 7500242-9500862 EXCEPT FOR, SEE FOOTN. 102, Replaced By: A3260531730, +002A3220530125, +002A3260530160
999
VALVE GUIDE , FROM ENGINE 7500242-9500862 EXCEPT FOR, SEE FOOTN. 102 NO LONGER AVAILABLE INDIVIDUALLY, Replaced By: A3260531630, +002A3220530125, +002A3260530160
999
VALVE GUIDE , FROM ENGINE 7500242-9500862 EXCEPT FOR, SEE FOOTN. 102, Replaced By: A3260531329, +002A3220530125, +002A3260530160
999
VALVE GUIDE , FROM ENGINE 7500242-9500862 EXCEPT FOR, SEE FOOTN. 102, Replaced By: A3260531229, +002A3220530125, +002A3260530160
999
VALVE GUIDE , FROM ENGINE 7500242-9500862 EXCEPT FOR, SEE FOOTN. 102, Replaced By: A3460530730, +001A3520530296
999
VALVE GUIDE , FROM ENGINE 7500242-9500862 EXCEPT FOR, SEE FOOTN. 102, Replaced By: A3260531129, +002A3220530125, +002A3260530160
999
VALVE GUIDE , UP TO ENGINE 027399,ALSO INSTALLED ON 027459,027464,027467, Replaced By: A3550530330, +001A3520530296
999
VALVE SEAT RING , FOR 326 010 49 20, 326 010 50 20
999
VALVE SEAT RING , FOR 326 010 49 20, 326 010 50 20
999
VALVE GUIDE , FROM ENGINE 7500242-9500862 EXCEPT FOR, SEE FOOTN. 102, Replaced By: A3260530029, +002A3220530125, +002A3260530160
999
SPRING RETAINER , Replaced By: A3260530325
999
BRACKET , Replaced By: A3260181040
999
BRACKET ,009825
999
FILTER , UP TO ENGINE 017705 EXCEPT FOR 015839,015887,015888,015993,015994,015997,016043,016115,016215,016328,016365,016463,016503,016544, 016741., Replaced By: A3260180560, +001A3260180312, +002N900262009100, +002N900263009033, +001N900271032008
999
FILTER , UP TO ENGINE 017705 EXCEPT FOR 015839,015887,015888,015993,015994,015997,016043,016115,016215,016328,016365,016463,016503,016544, 016741., Replaced By: A3260180560, +001A3260180312, +002N900262009100, +002N900263009033, +001N900271032008
999
BREATHER PIPE
999
FILTER , UP TO ENGINE 017705 EXCEPT FOR 015839,015887,015888,015993,015994,015997,016043,016115,016215,016328,016365,016463,016503,016544, 016741., Replaced By: A3260180560, +001A3260180312, +002N900262009100, +002N900263009033, +001N900271032008
999
PIN
999
CYLINDER HEAD GASKET
999
CYLINDER HEAD GASKET , Replaced By: A3260161520
999
CYLINDER HEAD GASKET , Replaced By: A3260161520
999
GASKET , Replaced By: A3660160421
999
GASKET , 910,912-918,971-977 013245 983,988 013245 911,977 011791, Replaced By: A3260160321, +001A3261410080
999
CYLINDER SIDE COVER ,030420, Replaced By: A3460150005
999
CYLINDER SIDE COVER , Replaced By: A3260150805
999
COVER , UP TO ENGINE 9502936 EXCEPT FOR 9502849-9502873,9502878-9502911,9502913-9502933
999
GASKET , Replaced By: A3550140122
999
GASKET , Replaced By: A3550140022
999
GASKET , TO 326 010 17 28
999
SIGHT GLASS , TO 326 010 17 28
999
GAUGE PLATE , TO 326 010 17 28
999
GASKET , TO 326 010 17 28
999
COVER , TO 326 010 17 28
999
CRANKSHAFT BEARING CAPNO. 7, NO LONGER AVAILABLE INDIVIDUALLY
