Поз.
Артикул
Описание
5
TANK OIL
5
TANK , Replaced By: A0004666202
8
OIL DIPSTICK , Replaced By: A0004660867
8
OIL DIPSTICK
11
FILLER CAP
11
FILLER CAP , Replaced By: A0004661268
14
SEAL RING
17
BRACKET
20
FILTER
20
FILTER
23
SCREW BRACKET TO CROSS MEMBER M 6X35
26
NUT PUMP TO BRACKET
26
NUT , Replaced By: N913004006001
29
BRACKET OIL TANK
29
BRACKET OIL TANK
32
SCREW CENTRAL LOCK TO CAB M 10X16
35
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
38
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
38
CLAMP , Replaced By: N000000000667
41
LINE HOSE TO SUCTION LINE AND TO OIL TANK
44
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
44
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
44
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,5 701910
44
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,K 033740
44
LINE FROM OIL TANK TO POWER STEERING PUMP AT ENGINE
44
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,K 033741
47
UNION NUT LINE CONNECTION, Replaced By: N000000006243
47
NUT LINE CONNECTION
50
SEAL CONE LINE CONNECTION
50
GLAND , Replaced By: A0019901267
53
FITTING SUCTION LINE TO OIL PUMP
53
ELBOW FITTING SUCTION LINE TO OIL PUMP
54
NUT SUCTION LINE TO OIL PUMP
55
THRUST RING SUCTION LINE TO OIL PUMP
56
SEALING CORD SUCTION LINE TO OIL PUMP
59
SCREW-IN FITTING DELIVERY LINE TO PUMP
59
FITTING DELIVERY LINE TO PUMP
62
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
65
LINE FROM PUMP TO HIGH PRESSURE HOSE
65
LINE FROM PUMP TO HIGH PRESSURE HOSE
65
LINE FROM PUMP TO HIGH PRESSURE HOSE, CIRCUIT I
65
LINE FROM PUMP TO HIGH PRESSURE HOSE
68
UNION NUT LINE CONNECTION, Replaced By: N000000006239
68
UNION NUT LINE CONNECTION
71
SEAL CONE LINE CONNECTION
71
GLAND , Replaced By: A0019901967
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
77
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING,5 964537K 062209
77
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING,K 033741
77
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING,K 062210
77
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX
80
UNION NUT LINE CONNECTION
80
UNION NUT LINE CONNECTION, Replaced By: N000000006239
83
GLAND , Replaced By: A0019901967
83
SEAL CONE LINE CONNECTION
86
FITTING DELIVERY LINE TO PUMP
86
SCREW-IN FITTING DELIVERY LINE TO PUMP
87
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
89
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
90
SEAL RING VALVE TO VALVE,K 025179
92
LINE RETURN, FROM STEERING TO OIL TANK
92
LINE RETURN, FROM STEERING TO OIL TANK
92
LINE RETURN, FROM STEERING TO OIL TANK
92
LINE RETURN, FROM STEERING TO OIL TANK
92
LINE RETURN, FROM STEERING TO OIL TANK
95
UNION NUT LINE CONNECTION
98
GLAND LINE CONNECTION
101
HOSE DELIVERY LINE TO STEERING
104
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
104
CLAMP HOSE TO FITTING AND TO OIL TANK
107
BRACKET FUEL LINES TO TRANSMISSION
110
BRACKET DELIVERY AND SUCTION LINES TO FRAME
113
SCREW , Replaced By: N308676012026
113
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
113
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
116
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
116
SCREW END PIECE TO EXHAUST PIPE M 10X25
122
WASHER
125
NUT SUPPORT TO SIDE MEMBER
128
NUT STRAP TO BRACKET
128
NUT , Replaced By: N910113010000
131
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
131
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
134
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
134
CLAMP DELIVERY AND SUCTION LINES TO STEERING
134
CLAMP , Replaced By: A6739950001
137
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
137
CLAMP DELIVERY AND SUCTION LINES TO FRAME
140
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
143
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
143
HEXALOBULAR BOLT CLAMP ON BRACKET M6X30
143
SCREW CLAMP MOUNTING M 6X16
143
SCREW , Replaced By: N000000001422
143
SCREW , Replaced By: N000000001146
146
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
146
WASHER COMPRESSED AIR LINE TO BRACKET
149
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
152
NUT PUMP TO BRACKET
152
NUT , Replaced By: N913004006001
999
LINE FROM HOSE TO OIL PUMP,011232
999
LINE FROM PUMP TO HIGH PRESSURE HOSE,011232
999
PROTECTIVE CAP
