Поз.
Артикул
Описание
9
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
9
PLASTIC PIPE AERATION, ORDER BY THE METER
18
FITTING (PARTS KIT),LINE RUPTURE
27
ELBOW FITTING HOSE WIDTH, 9 MM,TO M22
30
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
36
CONNECTOR HOSE WIDTH, 6 MM,TO M16
36
CONNECTOR , Replaced By: A0029905478
45
SEAL RING , Replaced By: A0009940747
45
LOCK RING LINE CONNECTION
45
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
54
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
54
LOCK LINE CONNECTION
54
LOCK , Replaced By: A0009945448
63
REPAIR KIT , Replaced By: A0309971748
63
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
63
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
72
VALVE (CHECK VALVE)
81
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
90
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
90
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
99
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
108
SCREW. UNION SCREW LINE CONNECTION
108
SCREW. UNION SCREW , Replaced By: A0009973734
117
BRAKE LINE COUPLING SUPPLY "KNORR"
117
BRAKE LINE COUPLING SUPPLY "WABCO"
126
SEAL RING"WABCO"
135
COVER"WABCO", NOT USED
144
REPAIR KIT"KNORR"
153
BRACKET BRAKE LINE COUPLING
153
BRACKET BRAKE LINE COUPLING,5 905818
153
BRACKET BRAKE LINE COUPLING,5 905819
162
FITTING LOAD/NO-LOAD VALVE,CONNECTION: "40",5 509133
171
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
180
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
189
SCREW. UNION SCREW LINE CONNECTION
207
SCREW BRACKET TO BRACKET
207
SCREW BRACKET TO CROSS CONNECTION STRUT
207
SCREW PIPE CLAMP
207
SCREW , Replaced By: N304017008034
207
SCREW , Replaced By: N304017008021
207
SCREW , Replaced By: N910142008001
216
NUT , Replaced By: N913004008001
216
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
216
NUT BRACKET TO BRACKET
225
LOOM TIE LINE MOUNTING
225
LOOM TIE LINE MOUNTING 280 MM
999
ELBOW FITTING HOSE WIDTH, 6 MM,TO M22
999
ELBOW FITTING , Replaced By: A0049905371
