Поз.
Артикул
Описание
5
COMPRESSOR
15
WOODRUFF KEY FLANGE TO SHIFTING TUBE
25
LOCK WASHER BELL HOUSING TO TRANSMISSION
36
NUT
46
OIL DIPSTICK
56
SEAL RING
66
BUSHING
76
GASKETTO 000 131 31 01
86
SEAL RING FROM POWER STEERING PUMP AT ENGINE TO CUT-IN VALVE
96
FITTING CONNECTION "2"
106
PIPE BEND , 910,912-971,973-975 9503595 972 9500150
116
HOSE , ORDER BY THE METER
116
HOSE , Replaced By: A4969970082
119
LOOM TIE HAND PUMP
122
STRAP165 MM, UP TO CHASSIS 772045 EXCEPT FOR:500000-599999 ORDER BY THE METER
126
PULLEY , FROM ENGINE 7500244-9502936 EXCEPT FOR,SEE FOOTN.010,WHEN USED WITH POWER STEERING PUMP,FROM ENGINE 7500155
126
PULLEY , 910,912-918,973-975 9502937 ALSO INSTALLED ON 9502849-9502873 9502878-9502911 9502913-9502933
136
NARROW V-BELT *** 12,5 X 1600 MM
146
SUPPORT
156
PIN AIR COMPRESSOR SUPPORT TO BEARING BODY
166
SPACER WASHER
176
LOCK WASHER BRACKET TO SUPPORT
186
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
191
CLAMPING SLEEVE
196
LOCK RING ,825817, 301,303,304,305, 868276, 311,313,314825818, 301,303,304,305, 868277, 311,313,314 SEE SPARE PARTS LIST 740.3
206
SCREW
216
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
226
SCREW (CLAMPING BOLT)
236
LOCK RING TO PULL OFF CONSOLE
241
NUT SPRING BOLT
246
NUT
256
WASHER , Replaced By: N000125008443
256
WASHER EXHAUST MUFFLER TO STRAP
266
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
276
SCREW BRACKET TO SIDE MEMBER
286
COMPRESSOR
296
WOODRUFF KEY FLANGE TO SHIFTING TUBE
306
LOCK WASHER BELL HOUSING TO TRANSMISSION
316
NUT , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
326
OIL DIPSTICK
336
SEAL RING
346
BUSHINGTO 000 131 31 01,8503165
356
PULLEY , 910,912-918,973-975 9502937 ALSO INSTALLED ON 9502849-9502873 9502878-9502911 9502913-9502933
356
PULLEY
366
SEAL RING FROM POWER STEERING PUMP AT ENGINE TO CUT-IN VALVE
376
NUT CHECK VALVE TO AIR RESERVOIR
386
ELBOW FITTING LINE CONNECTION
396
SCREW ANTI-FREEZE PUMP TO BRACKET,950272
406
INTAKE PIPE , 910,912,914,915,918,971,973,974,975 FROM ENGINE 9503595-012935,972 FROM ENGINE 9500150-012935,ORDER BY THE METER
416
PIPE BEND , 910,912-971,973-975 9503595 972 9500150
426
SEAL RING COMPRESSED AIR LINE TO CLUTCH BOOSTER WABCO
436
HOLLOW SCREW AIR DEHYDRATOR,CONNECTION: "21"
456
HOSE FROM EXPANSION TANK TO RADIATOR
466
HOSE CLAMP. LOOM TIE FUEL LINE, TYPE 1113B UP TO CHASSIS 604683,TYP LP 1517 UP TO CHASSIS 600412,TYPE LP 1317 UP TO CHASSIS 601123,TYPE LP 911 B UP TO CHASSIS601688 CONTINUED,SEE FOOTNOTE 003
476
STRAP165 MM, UP TO CHASSIS 772045 EXCEPT FOR:500000-599999 ORDER BY THE METER
486
LOOM TIE , Replaced By: N000000000668
486
CLAMP , Replaced By: A0069970490
486
CLAMP25-40X13 MM
999
OIL DIPSTICK , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0001301086
999
COMPRESSOR , Replaced By: A0001314801
999
COMPRESSOR , Replaced By: A0001318301
999
PIN ,9501686, Replaced By: A3151310274, +001N000471017000
999
PIN ,9501686, Replaced By: A3151310274, +001N000471017000
999
SUPPORT , Replaced By: A3261310135, +001A3261310071, +001A3261310072, +001A3269900901, +001N000127012202, +001N000471007000
999
HOSE15 MM,250 MM, 910,912-971,973-975 9503594 972 8503316
999
HOSE360 MM, 910,912-971,973-975 9503594 972 8503316
999
SCREW
999
SCREW
999
WASHER BRACKET TO SIDE MEMBER,5 703114
999
INTAKE PIPE , 910,912-971,973-975 9503594 972 8503316
999
PULLEY , UP TO ENGINE 7500243,WHEN USED WITH POWER STEERING PUMP,UP TO ENGINE 7500154
999
PULLEY , UP TO ENGINE 7500243,WHEN USED WITH POWER STEERING PUMP,UP TO ENGINE 7500154
