Поз.
Артикул
Описание
13
RADIATOR (OIL COOLER),ON RADIATOR
57
BRACKET AIR DUCT
74
BRACKET BRACKET TO SUPPORT AND TO BASE FRAME
74
BRACKET BRACKET TO SUPPORT AND TO BASE FRAME
107
RUBBER MOUNTING RADIATOR
152
AIR DUCT ADDITIONAL BLOWER
157
COVERING AIR DUCT
159
SCREW COVER PLATE TO COVER PLATE M 6 X 10
159
SCREW , Replaced By: N304017006034
161
BRACKET OIL COOLER,RIGHT TOP
161
BRACKET OIL COOLER,LEFT TOP
163
BRACKET FAN SHROUD,RIGHT
163
BRACKET FAN SHROUD,LEFT
165
BRACKET BRACKET TO BRACKET
167
THREADED UNION BRACKET TO OIL COOLER,TOP
169
THREADED UNION BRACKET TO OIL COOLER,BOTTOM
171
BUSHING BRACKET TO OIL COOLER,BOTTOM
173
BRACKET OIL COOLER,LEFT BOTTOM
173
BRACKET OIL COOLER,RIGHT BOTTOM, SIMPLE PART-PLEASE HAVE SHOP MADE
175
WASHER EXHAUST MUFFLER TO STRAP
175
WASHER , Replaced By: N000125008443
177
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
179
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
179
SCREW , Replaced By: N304017008016
181
SCREW , Replaced By: N304017006020
181
SCREW LICENSE PLATE TO BRACKET
183
FAN SHROUD RADIATOR
185
SCREW PUMP TO BRACKET
185
SCREW , Replaced By: N304017006016
187
WASHER , Replaced By: N000988008024
187
FITTED WASHER
191
BRACKET AIR DUCT
191
BRACKET AIR DUCT
199
SCREW DUMPER SHAFT,5 515436
199
SCREW , Replaced By: N304014010015
201
SPACER TUBE RADIATOR STRUT TO SUPPORT AND TO CAB
201
SPACER TUBE HOLLOW RUBBER SPRING,5 956657
203
RUBBER BUFFER CHARGE AIR INTERCOOLER
205
WASHER BRACKET TO COVERING
205
WASHER , Replaced By: N009021010209
211
SPACER TUBE BRACKET TO CONSOLE
211
SPACER TUBE BRACKET TO CONSOLE
215
WASHER BRACKET TO FRAME
215
WASHER , Replaced By: N000125017016
219
STUD BRACKET TO CONSOLE
223
NUT CONSOLE TO SUPPORT
223
NUT , Replaced By: N910113016001
241
BRACKET BASE FRAME
999
SUPPORT RADIATOR,LEFT
999
BRACKET RADIATOR TO FRAME
999
BRACKET AIR DUCT TO CONSOLE
999
BRACKET AIR DUCT TO CONSOLE
999
BRACKET AIR DUCT TO CONSOLE
999
BRACKET RADIATOR TO FRAME
999
BRACKET RADIATOR TO FRAME
999
COVERING BLOWER
999
NUT STRAP TO BRACKET
999
NUT , Replaced By: N910113010000
