Поз.
Артикул
Описание
5
BRAKE VALVE SERVICE BRAKE WABCO
5
BRAKE VALVE SERVICE BRAKE KNORR
8
LOCKTO 345 431 70 05
11
SPRINGTO 345 431 71 05
11
SPRINGTO 345 431 70 05
11
SPRINGTO 345 431 70 05
20
PISTONTO 345 431 70 05
20
PISTONTO 345 431 71 05
26
LOCK RING PLANETARY CARRIER
26
LOCK RING
26
LOCK RINGTO 345 431 71 05
26
LOCK RINGTO 345 431 71 05
38
REPAIR KIT , Replaced By: A0014300460
38
REPAIR KIT LARGE SCOPE TO 345 431 70 05
38
REPAIR KIT SMALL SCOPE TO 345 431 71 05
38
REPAIR KIT SMALL SCOPE TO 345 431 70 05
44
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
44
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
47
WASHER TRAILER PLUG SOCKET TO BRACKET
50
ROD FROM FITTING TO CLUTCH BOOSTER
50
ROD , Replaced By: A3842927032, +001A3849967001, +001N000934012009
53
YOKE
56
NUT FUEL TANK TO SUPPORT
59
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
62
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
65
SEAL RINGTO 006 997 00 72
68
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
71
VALVE (CHECK VALVE)
71
VALVE (CHECK VALVE)
71
VALVE (CHECK VALVE)
71
VALVE (CHECK VALVE)
71
VALVE (CHECK VALVE)
71
VALVE (CHECK VALVE)
74
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
77
SEAL RING LINE CONNECTION
80
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
80
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
83
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
86
SEAL RINGTO 006 997 00 72
86
SEAL RINGTO 006 997 00 72
90
FITTING VALVE TO VALVE
94
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
98
VALVE (RELAY VALVE) WABCO
98
VALVE (RELAY VALVE) KNORR
98
VALVE (RELAY VALVE),REAR AXLE
101
REPAIR KITTO 003 429 30 44,KNORR
101
REPAIR KIT SMALL SCOPE TO 001 429 68 44
101
REPAIR KITWABCO
101
REPAIR KITKNORR
104
BRACKET (RELAY VALVE)
107
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
107
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
110
WASHER TRAILER PLUG SOCKET TO BRACKET
113
BRACKET
116
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
116
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
119
ADAPTER FITTING COMPRESSED AIR LINE THRU LEFT FRAME SIDE MEMBER
125
WASHER COILED TUBE TO BRAKE LINE COUPLING SUPPORT
128
TOOTHED WASHER SENDER UNIT TO BRACKET
131
NUT BRACKET TO SIDE MEMBER
134
T-FITTING FROM CHECK VALVE TO RELAY VALVE
134
T-FITTING FROM CHECK VALVE TO RELAY VALVE
137
NUT CHECK VALVE TO AIR RESERVOIR
137
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
143
THRUST RING CHECK VALVE TO AIR RESERVOIR
143
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
143
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
143
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
143
THRUST RING LOCKING VALVE
149
O-RING CHECK VALVE TO AIR RESERVOIR
149
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
155
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
158
SEAL RING LINE CONNECTION
161
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
164
SEAL RINGTO 006 997 00 72
167
T-FITTING DIAPHRAGM CYLINDER,CONNECTION: "11",5 272559
170
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
173
THRUST RING LOCKING VALVE
176
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
179
SWITCH RELAY VALVE,CONNECTION "2",RIGHT
179
SWITCH SUPPLY PRESSURE,5 966147
182
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
185
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
197
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
200
THRUST RING LOCKING VALVE
203
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
206
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
209
SEAL RINGTO 006 997 00 72
212
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
215
SEAL RINGTO 006 997 00 72
