Поз.
Артикул
Описание
5
FRONT EXHAUST PIPE , 962132 N 000000 P 000000
8
FLANGE , FROM IDENT NO. 003 038515 ALSO INSTALLED ON 038269,038362,038363.
11
EXHAUST PIPE FRONT PART, 962133 N 000001 P 000001
14
EXHAUST PIPE FRONT,SECOND PART, 962133 N 000001 P 000001
17
SCREW STRAP TO EXHAUST MUFFLER
20
HEXAGON NUT SCREENING PLATE,5 163561
20
NUT , Replaced By: A1201420072
23
CLAMP FRONT EXHAUST PIPE, FROM IDENT NO.691884, P 000001 ALSO INSTALLED ON 689886,689929,690037,690093,691039,691040,691041,691042,691043,691709. ALSO FOR USE AFTER INSTALLATION OF REPAIR SOLUTIONP 275512
26
HEXAGON HEAD BOLT BRACKET TO NO.1 CROSS MEMBER M8X35
29
HEXAGON NUT SCREENING PLATE,5 163561
29
NUT , Replaced By: A1201420072
32
EXHAUST MUFFLER
35
CLAMP , Replaced By: A1074920140
35
CLAMP , 003 078976 086 003333 EXCEPT FOR 002924,002958,002959,002981,003004,003013,003017,003025,003114,003171,003282-003298,003300-003332.
35
CLAMP , Replaced By: A1074920340
38
SCREW STRAP TO EXHAUST MUFFLER
41
WASHER BRACKET TO CROSS MEMBER
44
HEXAGON NUT SCREENING PLATE,5 163561
44
NUT , Replaced By: A1201420072
47
BRACKET FRONT EXHAUST PIPE, 962132 N 000000 P 000000
50
BRACKET FRONT EXHAUST PIPE TO TRANSMISSION G 1/18, 962133 N 000001 P 000001
53
BRACKET FRONT EXHAUST PIPE TO TRANSMISSION, FROM IDENT NO. 941506 ALSO INSTALLED ON 899081-941503 ONLY WITH OM601/OM602 ENGINEP 000001
56
HEXAGON HEAD BOLT. SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
59
WASHER , Replaced By: N009021008213
59
WASHER BRACKET TO LEFT SIDE MEMBER
62
NUT , Replaced By: A1201420072
62
HEXAGON NUT SCREENING PLATE,5 163561
65
CLAMPING BRACKET FRONT EXHAUST PIPE TO BRACKET, 962132 N 000000 P 000000
65
CLAMPING BRACKET EXHAUST PIPE TO BRACKET
68
SPRING WASHER STEERING COLUMN BRACKET TO CAB
71
WASHER BRACKET TO CROSS MEMBER
74
NUT CROSS MEMBER TO SIDE MEMBERS
77
HEXAGON NUT SCREENING PLATE,5 163561
77
NUT , Replaced By: A1201420072
80
BRACKET EXHAUST PIPE TO SIDE MEMBER, 962133 N 000001 P 000001
83
ANGLE AT BRACKET IN FRAME SIDE MEMBER, 962133 N 000001 P 000001 SIMPLE PART-PLEASE HAVE SHOP MADE
86
SCREW PUMP TO BRACKET
89
WASHER SWITCH TO FIRE WALL
92
NUT HEATING PIPE TO BRACKET
95
SCREW STRUT TO CROSS MEMBER M 10X25
98
NUT CROSS MEMBER TO SIDE MEMBERS
101
CLAMP , Replaced By: A6554314640
110
NUT STRAP TO BRACKET
113
BRACKET TAIL PIPE
116
SCREW STRUT TO CROSS MEMBER M 10X25
119
WASHER RADIATOR TO RUBBER MOUNTING
122
NUT CROSS MEMBER TO SIDE MEMBERS
125
CLAMP AT MUFFLER
125
CLAMP , Replaced By: A6674900141
128
SCREW CABLE HARNESS MOUNTING
134
HEXAGON NUT SCREENING PLATE,5 163561
134
NUT , Replaced By: A1201420072
137
SCREW PILLAR TO BRACKET AND TO FRONT PANEL
137
HEXAGON HEAD BOLT. SCREW OIL SEPARATOR TO TRANSMISSION CASE
137
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
140
NUT STRAP TO BRACKET
143
SUSPENSION EXHAUST MUFFLER TO BRACKET
146
REAR EXHAUST PIPE (TAIL PIPE)
149
BRACKET TAIL PIPE
152
SCREW STRUT TO CROSS MEMBER M 10X25
155
WASHER RADIATOR TO RUBBER MOUNTING
158
NUT CROSS MEMBER TO SIDE MEMBERS
161
CLAMP LINE MOUNTING
161
CLAMP , Replaced By: N000000001641
161
CLAMP , Replaced By: A9424310043
164
BRACKET REAR EXHAUST PIPE TO BRACKET
167
SCREW BRACKET TO CROSS CONNECTION STRUT
170
WASHER BRACKET TO ENGINE MOUNTING USED WITH FIVE-SPEED TRANSMISSION
170
WASHER FRONT AND REAR EXHAUST PIPES TO MUFFLER
173
NUT , Replaced By: A1201420072
173
HEXAGON NUT SCREENING PLATE,5 163561
176
HEXAGON HEAD BOLT. SCREW OIL SEPARATOR TO TRANSMISSION CASE
179
NUT STRAP TO BRACKET
182
SUSPENSION EXHAUST MUFFLER TO BRACKET
999
CLAMP , Replaced By: N000000000671
999
HEXAGON HEAD BOLT BRACKET TO BRACKET
999
CLAMP SUCTION LINE TO OIL PUMP 40-60X13 MM
999
WASHER
999
BRACKET , Replaced By: A6684923641
999
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6684923441
999
BRACKET TAIL PIPE
999
REAR EXHAUST PIPE , Replaced By: A6674922204
999
REAR EXHAUST PIPE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 789758 N 000000 P 000000, Replaced By: A6674921904
999
REAR EXHAUST PIPE , Replaced By: A6674921304, +001A6674922041
999
REAR EXHAUST PIPE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 753730 N 000000 P 000000, Replaced By: A6674921804
999
CLAMP , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6674900241
999
EXHAUST PIPE
999
EXHAUST PIPE , Replaced By: A6674900719
999
PROTECTIVE PLATE
999
CLAMP , Replaced By: A1074900041
