Поз.
Артикул
Описание
20
PLASTIC PIPE RISING PIPE 4X6 MM
20
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
23
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
26
UNION NUT
29
GLAND , Replaced By: A0019901667
32
SLEEVE LEAK LINE
35
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
35
CONNECTOR , Replaced By: A0029905378
41
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
44
SEAL RING , Replaced By: A0009940747
44
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
44
LOCK RING LINE CONNECTION
47
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
47
LOCK , Replaced By: A0009945448
47
LOCK LINE CONNECTION
50
REPAIR KIT , Replaced By: A0309971748
50
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
50
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
53
BRACKET SENSOR CABLE TO FRONT AXLE
56
LOOM TIE LINE MOUNTING 280 MM
56
LOOM TIE LINE MOUNTING
59
DISTRIBUTOR ENGINE SHUT-OFF,5 766894
62
SCREW CONNECTOR
65
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
68
NUT , Replaced By: N913004006001
68
NUT PUMP TO BRACKET
71
SCREW. UNION SCREW , Replaced By: A0009973734
71
SCREW. UNION SCREW LINE CONNECTION
71
SCREW. UNION SCREW LINE CONNECTION
77
PLUG DISTRIBUTOR,CONNECTIONS: "03,04,05",TO M 16,5 766894
80
VALVE EXHAUST BRAKE 3/2-WAY VALVE BOSCH
80
VALVE EXHAUST BRAKE 3/2-WAY VALVE WABCO
83
CUP 3/2-WAY VALVE WABCO
86
REPAIR KIT 3/2-WAY VALVE BOSCH
86
REPAIR KIT 3/2-WAY VALVE WABCO
89
NUT SUCTION LINE TO OIL PUMP
92
SPRING WASHER AT CAB FLOOR
98
PIPE SOCKET 3/2-WAY VALVE,CONNECTION: "30"
107
SCREW. UNION SCREW LINE CONNECTION
107
SCREW. UNION SCREW , Replaced By: A0009973734
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
SCREW , Replaced By: N304017006034
999
BRACKET DISTRIBUTOR TO CAB
999
CONNECTOR DISTRIBUTOR OUTPUT, COMPRESSED AIR LINE PLUG CONNECTION
999
CONNECTOR DISTRIBUTOR TO CAB
999
SEAL RING
999
CONNECTOR HOSE WIDTH, 6 MM,TO M16
999
ELBOW FITTING
999
ELBOW FITTING HOSE WIDTH, 9 MM,TO M22
999
CONNECTOR , Replaced By: A0029905478
