Поз.
Артикул
Описание
105
BRACKET HOSE TO OIL DIPSTICK GUIDE TUBE,K 130676
105
CLAMP , Replaced By: N916016015202
105
CLAMP LINE MOUNTING
110
CLAMP OIL FILLER PIPE TO BRACKET
110
BRACKET , Replaced By: A6734661040
110
BRACKET WITH PLUG,K 130676
380
BRACKET DELIVERY AND SUCTION LINES,5 374584
380
BRACKET DELIVERY AND SUCTION LINES,5 1382945 374583
385
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
385
SCREW , Replaced By: N304017010028
390
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
395
BRACKET DELIVERY AND SUCTION LINES
400
BRACKET FUEL LINE TO BELL HOUSING
400
BRACKET , Replaced By: A6454310740
405
BRACKET DELIVERY LINE TO FRAME
410
SCREW , Replaced By: N304017012020
410
SCREW END PIECE TO EXHAUST PIPE M 12X30
415
SCREW , Replaced By: N304017010002
415
SCREW BRACKET TO SIDE MEMBER
420
SCREW , Replaced By: N304017008021
420
SCREW PIPE CLAMP
425
NUT END PIECE TO EXHAUST PIPE
430
NUT , Replaced By: N910113010000
430
NUT STRAP TO BRACKET
435
NUT , Replaced By: N913004008001
435
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
440
CLAMP CABLE HARNESS MOUNTING
440
CLAMP , Replaced By: N916016010211
440
CLAMP , Replaced By: N000000001045
445
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
445
CLAMP LINE MOUNTING
445
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
445
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
450
BRACKET DELIVERY AND SUCTION LINES TO ENGINE
460
BRACKET DELIVERY AND RETURN LINES,5 529814K 055043
465
BRACKET DELIVERY AND SUCTION LINES,5 542691
470
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
470
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
470
CLAMP DELIVERY AND SUCTION LINES TO FRAME
475
SCREW , Replaced By: N304017006020
475
SCREW LICENSE PLATE TO BRACKET
475
SCREW COVER PLATE TO BRACKET
485
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
485
HEXALOBULAR BOLT CLAMP ON BRACKET M6X30
485
SCREW , Replaced By: N000000001422
490
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
490
WASHER COMPRESSED AIR LINE TO BRACKET
495
NUT PUMP TO BRACKET
495
NUT , Replaced By: N913004006001
500
SCREW , Replaced By: N304017008021
500
SCREW PIPE CLAMP
999
LINE12 MM, ORDER BY THE METER4 691315
999
LINE (DELIVERY LINE) FROM FITTING TO STEERING
999
JOINT R.H. THREAD LEMFOERDER,5 180856
999
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
999
SCREW BRACKET TO CONSOLE M 12X1.5X65
999
FITTING DELIVERY LINE TO PUMP
999
PROTECTIVE CAP
999
WASHER LEVER TO BRACKET 30X10.5X4 MM
999
BRACKET FEED LINE AND RETURN LINE,5 346007
999
LINE , Replaced By: A0004291001
999
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING,5 955601
999
BOOT STEERING SHAFT
999
BRACKET , Replaced By: A6173020440
999
BRACKET AIR INTAKE PIPE
999
HOSE ,K 055044
999
HOSE (DELIVERY LINE),FROM PUMP TO STEERING,K 126844
999
LINE , Replaced By: A0004292301
999
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX,5 163366
999
LINE (RETURN LINE),FROM STEERING TO OIL TANK,5 163366
999
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX,K 244309
999
PITMAN ARM
999
PITMAN ARM
999
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,5 163366
999
HOSE (DELIVERY LINE),FROM PUMP TO STEERING,K 126844
999
STEERING SHAFTLEMFOERDR,520 MM,5 404617
999
STEERING SHAFT , Replaced By: A6824607309
999
DRAG LINKLEMFOERDER
999
PITMAN ARM
999
PITMAN ARM , Replaced By: A6754631701
999
PITMAN ARM ,K 055089
999
PITMAN ARM ,K 055089
999
PITMAN ARM ,K 244310
999
PITMAN ARM ,K 244310
999
PITMAN ARM ,K 244310
999
PITMAN ARM ,K 244310
999
DRAG LINKEHRENREICH,5 424630
999
DRAG LINKEHRENREICH,5 424630
999
DRAG LINKLEMFOERDER,K 055089
999
DRAG LINKLEMFOERDER,K 055089
999
PITMAN ARM ,5 424630
999
PITMAN ARM ,5 424630
999
SCREW , Replaced By: N308676016020
999
SCREW-IN FITTING FROM DELIVERY LINE TO STEERING
999
SCREW CONSOLE TO FRAME
