Поз.
Артикул
Описание
3
HOSE FEED & RETURN 13X1.5 MM, ORDER BY THE METER
5
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
8
PLASTIC PIPE8X6 MM, ORDER BY THE METER
11
FITTING (PARTS KIT),LINE RUPTURE
19
HOSE FEED LINE AND RETURN LINE
20
HOSE SENDER UNIT,D 203093
20
HOSE AT SENDER UNIT,D 314240
21
CLAMP , Replaced By: N916017011001
25
BANJO UNION CONNECTION OF FUEL LINES
25
BANJO UNION
27
BANJO UNION10/14
29
HOLLOW SCREW
30
HOLLOW SCREW FUEL LINE TO FUEL TANK
31
BANJO UNION HOSE WIDTH, / I.D., 6/14 MM
32
CLAMP HOSE TO FITTING AND TO OIL TANK
32
CLAMP HOSE TO FITTING AND TO OIL TANK
34
SEAL RING INJECTION PUMP
37
CONNECTOR
38
VALVE , Replaced By: A3760980057
38
VALVE
39
CONNECTOR LINE CONNECTION
41
NUT. UNION NUT RETURN
42
UNION NUT RETURN LINE
43
INSULATING HOSE , ORDER BY THE METER
43
HOSE WITHE
43
INSULATING HOSE CHECK VALVE,CONNECTION "2"
43
HOSE VIOLET
44
LOOM TIE , Replaced By: A3459977390
44
LOOM TIE ELECTRIC CABLE MOUNTING
47
HOSE RETURN LINE TO ENGINE, ORDER BY THE METER
47
HOSE , ORDER BY THE METER
53
CLAMP LINE MOUNTING
56
BUSHING FUEL LINE THRU FRAME SIDE MEMBER
62
BRACKET POS. CABLE,XB209706
63
WASHER , Replaced By: A3609902340
64
BRACKET , Replaced By: A3464296040
65
BRACKET BATTERY CABLE
66
BRACKET AT RIGHT SIDE MEMBER
69
SCREW ELECTRICAL COMPARTMENT
71
NUT
72
SCREW BRACKET TO BUMPER,LEFT M 10X25
73
NUT BRACKET TO SIDE MEMBER,XB209706
78
CLAMP FUEL LINES TO BRACKET
81
SCREW CLAMP TO BRACKET M 6X25
82
WASHER PLUG SOCKET TO BRACKET
86
CLAMP HOSE TO FLANGE AND TO VALVE
89
LOOM TIE COMPRESSED AIR LINE MOUNTING 381 MM
89
LOOM TIE AIR INTAKE HOSE TO CLAMP
89
LOOM TIE LINE MOUNTING
999
BRACKET MANUAL PUMP AND PREFILTER
