Поз.
Артикул
Описание
9
BRACKET ACCELERATOR PEDAL SWITCH
14
SWITCH , Replaced By: A3575407645
14
SWITCH (LEVEL SWITCH)
20
WASHER COILED TUBE TO BRAKE LINE COUPLING SUPPORT
26
SCREW COVER PLATE TO BRACKET
32
NUT , Replaced By: N913004006001
32
NUT PUMP TO BRACKET
38
STOP
44
SCREW BRACKET ON LOAD SENSOR
50
NUT , Replaced By: N913004006001
50
NUT PUMP TO BRACKET
140
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
146
SWITCH EXHAUST BRAKE
152
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
152
PLASTIC PIPE AERATION, ORDER BY THE METER
152
PLASTIC PIPE AERATION, ORDER BY THE METER
158
FITTING (PARTS KIT),LINE RUPTURE
164
UNION NUT LINE CONNECTION
170
GLAND LINE CONNECTION
176
SLEEVE LINE CONNECTION
182
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
182
BANJO UNION LINE CONNECTIONS
182
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
188
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
188
PLASTIC PIPE RISING PIPE 4X6 MM
188
PLASTIC PIPE RISING PIPE 4X6 MM
194
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
200
UNION NUT
206
GLAND , Replaced By: A0019901667
212
SLEEVE LEAK LINE
218
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
224
FITTING TEST VALVE TO RELAY VALVE,CONNECTION: "40"
230
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
236
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
242
T-FITTING 3/2-WAY VALVE
248
T-FITTING. FITTING AT INJECTION PUMP
254
VALVE SOLENOID VALVE,5 450429 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
254
VALVE , Replaced By: A0049975736
254
VALVE (3/2-WAY SOLENOID VALVE) EKS
260
PROTECTIVE CAPWABCO
266
VALVE PARTTO 004 997 00 36,5 757289 AUSSERDEM EINGEBAUT IN 5 759173
272
SEAL RINGWABCO
278
SEAL RING VALVE TO VALVE
284
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
290
HOLLOW SCREW HEATING CONNECTION
296
SEAL RING LINE CONNECTION
302
SCREW , Replaced By: N304017008043
302
SCREW VALVE TO BRACKET M 8X55
308
NUT , Replaced By: N913004008001
314
WASHER , Replaced By: N000125008443
314
WASHER EXHAUST MUFFLER TO STRAP
320
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0024299544
320
VALVE TWO-WAY VOSS
326
VALVE BODYTO 002 429 95 44
332
BALLTO 003 429 22 44
338
GASKETTO 003 429 22 44
344
FITTING HYDRAULIC LINE TO BRACKET,K 130132
350
NUT , Replaced By: N308675012000
350
NUT CAB FLOOR
356
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
362
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
368
FITTING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
374
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
380
O-RING CHECK VALVE TO AIR RESERVOIR
386
HOLLOW SCREW HEATING CONNECTION
392
SEAL RING LINE CONNECTION
