Поз.
Артикул
Описание
5
HOUSING (SHIFTER COVER)
8
GASKET SHIFT CASE TO TRANSMISSION
11
SCREW PLATE TO TRANSMISSION CASE M 8 X 70
14
SPRING WASHER , Replaced By: N000137008212
26
SHIFTING SHAFT
29
NEEDLE BEARING REAR DRIVE SHAFT
29
NEEDLE BEARING , Replaced By: A0059813110
32
SEAL RING SHIFTING SHAFT
35
BOOT SHIFTING SHAFT
38
COVER SHIFT LEVER TO TRANSMISSION
41
SHIFT LEVER
44
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
47
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
50
SHIFTING FINGER
53
LOCK-OUT
53
LOCK-OUT
56
CONNECTING DRUM
59
CLAMPING SLEEVE LEVER TO CONSOLE 8X36MM
62
CLAMPING PIN PLANET GEAR
65
WASHER
68
SPRING SHIFTING SHAFT
71
SPACER TUBE SHIFTING SHAFT
74
LOCK
77
BUSHING SHIFTING SHAFT BEARING
80
BUSHING SHIFTING SHAFT BEARING
83
LOCK RING , Replaced By: N000472032001
85
PRESSURE SWITCH BACK-UP LIGHT
87
CLAMPING PIN NEUTRAL POSITION SWITCH
89
SPACER WASHER AS REQUIRED 2.0 MM
92
BUSHING
95
SPRING OIL DISTRIBUTOR BLOCK
98
SCREW PLUG CONVERTER HOUSING
101
SEALING RING. SEAL RING OIL DRAIN
104
DETENT
107
SEAL RINGTO 006 997 00 72
110
BREATHER , Replaced By: A3432640089
