Поз.
Артикул
Описание
275
CONSOLE , 674067
276
BASE AIR RESERVOIR TO CONSOLE
276
BASE ,A 069205
280
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
281
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
282
NUT BRACKET TO LEFT SIDE MEMBER
283
SHIM RESERVOIR
284
PLATE CONSOLE TO SIDE MEMBER
284
PLATE STRAP
285
SCREW REAR CROSS MEMBER AND GUSSET PLATES TO SIDE MEMBERS M 12X30
292
STRAP AIR RESERVOIR TO CONSOLE
294
NUT CLUTCH PEDAL RESET
294
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
303
HOSE , Replaced By: A0009872827
303
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
304
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM,026097
305
LOOM TIE , Replaced By: A0019978390
321
BRAKE VALVE (SERVICE BRAKE VALVE) WABCO
321
BRAKE VALVE (SERVICE BRAKE VALVE) KNORR
321
BRAKE VALVE SERVICE BRAKE KNORR
321
BRAKE VALVE , Replaced By: A3454317005
321
BRAKE VALVE SERVICE BRAKE WABCO
322
LOCK , Replaced By: N000472060000
323
LOCK RING
323
LOCK RING PLANETARY CARRIER
323
LOCK RINGTO 345 431 71 05
323
LOCK , Replaced By: N000472045000
324
LOCK RINGTO 345 431 71 05
324
LOCK , Replaced By: N000984038000
325
LOCK , Replaced By: N000472047001
325
LOCKTO 345 431 70 05
326
SPRINGTO 345 431 70 05
327
SPRINGTO 345 431 70 05
328
SPRINGTO 345 431 71 05
329
FILLER RINGTO 001 431 83 05,WABCO
330
BREATHER PIPETO 001 431 83 05,WABCO
331
PISTONTO 345 431 71 05
331
PISTONTO 001 431 83 05,WABCO
332
REPAIR KIT SMALL SCOPE TO 345 431 70 05
332
REPAIR KIT LARGE SCOPE TO 345 431 70 05
332
REPAIR KIT SMALL SCOPE TO 345 431 71 05
332
REPAIR KIT , Replaced By: A0004304206
332
REPAIR KITKNORR
332
REPAIR KIT , Replaced By: A0014300460
385
HOLLOW SCREW LINE TO OIL RADIATOR
386
HOLLOW SCREW FUEL FEED,AT WATER SEPARATOR
387
SEAL RINGTO 006 997 00 72
388
TEST CONNECTION
388
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
389
ELBOW FITTING SERVICE BRAKE VALVE,CONNECTION: "11,12",A 083335
389
ELBOW FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
390
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
391
THRUST RING LOCKING VALVE
392
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
400
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
401
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
415
SCREW MOUNTING CLAMP TO BRACKET AND TO FRAME
416
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
417
NUT , Replaced By: N913004008001
999
REPAIR KIT SMALL SCOPE TO 001 429 68 44
999
PISTONTO 002 431 27 05
999
PISTONTO 002 431 27 05
999
PISTONTO 345 431 70 05
999
VALVE DISCTO 000 429 48 30
999
SPRINGTO 001 431 83 05
999
LINE , Replaced By: A3214291202
999
REPAIR KITTO 002 430 31 01,344 430 80 01
999
REPAIR KIT , Replaced By: A0445860042
999
BRACKET , Replaced By: A0414280040
999
END PIECE , Replaced By: A3224200347, +001A3529910707
999
ROD , Replaced By: A3534200088
999
BRAKE LEVER , Replaced By: A3414200212
999
RESERVOIR ,5 936755, Replaced By: A0034322701, +002A0009970934
999
ANGLE , Replaced By: A3414280040
999
ANGLE , Replaced By: A3414280040
999
BRACKET COMPRESSED AIR LINE MOUNTING
999
BRACKET RIGHT,DIAPHRAGM CYLINDER
999
BRACKET LEFT,DIAPHRAGM CYLINDER
999
SCREW
999
NUT
999
BRACKET , Replaced By: A3414280040
999
BRACKET , Replaced By: A3414290340
999
SCREW LINE TO HOSE
999
SCREW FUEL LINE TO BRACKET
999
SCREW PROTECTION PLATE TO BRACKET
999
SCREW FUEL LINE TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER , Replaced By: N000125010532
999
WASHER
999
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
999
LOCK WASHER CLAMP TO BRACKET
999
LOCK WASHER , Replaced By: N912004010102
999
LOCK WASHER REINFORCEMENT ANGLE TO SIDE MEMBER, 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
999
WASHER 6,4 DIN 433. WASHER BRAKE LINE MOUNTING
999
SCREW PRESSURE REGULATOR TO BRACKET M 8X75
999
SCREW RIGHT COVERING
999
SCREW
999
SCREW COMPRESSED AIR ELBOW
999
SCREW ,1401150112256208
999
SCREW STEERING SHAFT BEARING TO CAB M 8X20
999
SCREW INTERMEDIATE PIECE,ADAPTER HOUSING
999
SCREW , Replaced By: N304017010002
999
SCREW BRACKET TO BUMPER,LEFT M 10X25
999
HEX. NUT M 4 DIN 934-5 S. NUT FUEL CONSUMPTION DISPLAY
999
NUT BALL PIVOT TO LEVER
999
NUT CLAMP TO BRACKET
999
NUT LEVER TO SHIFTING SHAFT
999
NUT TAIL LAMP TO BRACKET
999
NUT BRACKET TO FRAME
999
PIN , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
SEAL RING LINE CONNECTION
999
WASHER , Replaced By: N009021006208
999
LOCK WASHER
